Brother MFC-J5730DW Service Manual

5-21
Confidential
1.3.11 PCL/PS function setting (Maintenance mode 45)
< Function >
This function is used to change the settings of the PCL/PS functions summarized in the
table below.
< Operating Procedure >
(1) Press the 4 and 5 keys in this order in the initial stage of the maintenance mode.
“JB-Can Time” is displayed on the LCD.
(2) Press the ▲ or ▼ key to select the function you want to set and press the SET key.
(3) For fixed parameters (On/Off, etc.), press the ▲ or ▼ key, or change the
parameter using the numeric keys. And press the SET key.
For parameters requiring numerical value entry, directly input a numeric value from
the ten-key pad and press the SET key.
(4) Press the X key to return the machine to the initial state of the maintenance mode.
■ Function setting
LCD
Detail description Set value Initial
JB-Can Time
Setting of the time until the host time-out at
the Job Cancel
0 to 225 (seconds) 4 (seconds)
Sleep Time
Setting of the time until enter the Sleep
Mode
0 to 99 (minutes) 5 (minutes)
Emulation Switching of the emulation Driver/Auto/PCL/PS Driver
Auto I/F Time Switching of the I/F open time 1 to 99 (seconds) 5 (seconds)
Media Type Switching of the paper type Plain/Glossy/Inkjet Plain
Paper Size Switching of the drawing size
Letter/Legal/A4/
Executive/B5/JISB5/A5/
B6/A6/Monarch/C5/
COM10/DL/DLL/
A4Long/Post Card/
Folio/Mexican Legal/
India Legal/A3/B4/16k
195x270
Letter or A4
Orientation Switching of the print direction Portrait/Landscape Portrait
Auto FF Switching of the auto form feed On/Off Off
Auto FF Time
Switching of the time-out period of the auto
form feed
1 to 99 (seconds) 5 (seconds)
Auto LF Switching of the auto LF On/Off Off
Auto CR Switching of the auto CR On/Off Off
Auto WRAP
Switching of the auto CRLF at the print width On/Off Off
Auto Skip
Switching of the Skip at the backend/tip of
the paper
On/Off On
Left Margin Switching of the margin at the left end 0 to 145 (columns) 0 (columns)
Right Margin Switching of the margin at the right end 10 to 155 (columns)
80
(columns)
Top Margin Switching of the margin at the upper end 0 to 2.00 (inches) 0.5 (inches)
Bottom Margin Switching of the margin at the bottom end 0 to 2.00 (inches) 0.5 (inches)
Lines Number of the text lines in the page 5 to 128 (lines) 60 (lines)
Error Print
Switching of the ErrorPrint of the
PostScript
On/Off On

Brother MFC-J5730DW Specifications

General

Duplex printing	Yes
Print technology	Inkjet
Maximum resolution	1200 x 4800 DPI
Print speed (ISO/IEC 24734) mono	22 ipm
Print speed (ISO/IEC 24734) color	20 ipm
Time to first page (black, normal)	6 s
Duplex print speed (ISO/IEC 24734) mono	12 ipm
Duplex print speed (ISO/IEC 24734) color	11 ipm
Print speed (black, normal quality, A4/US Letter)	35 ppm
Print speed (color, normal quality, A4/US Letter)	27 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Copy speed (black, normal quality, A4)	12 cpm
Copy speed (color, normal quality, A4)	9 cpm
Scan to	E-mail, E-mail Server, FTP, File, Image, OCR, USB
Scanner type	Flatbed & ADF scanner
Input color depth	48 bit
Maximum scan area	210 x 297 mm
Output color depth	24 bit
Scan speed (color)	14 ppm
Maximum scan resolution	19200 x 19200 DPI
Duplex scan speed (color)	10 ppm
Optical scanning resolution	1200 x 1200 DPI
Faxing	Mono faxing
Fax memory	200 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	100
Display	LCD
Control type	Touch
Product color	Black
Display diagonal	3.66 \
Market positioning	Business
Internal memory	256 MB
Card reader integrated	No
Sound pressure level (printing)	50 dB
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	1
Package depth	469 mm
Package width	639 mm
Package height	511 mm
Package weight	24300 g
Power consumption (off)	0.04 W
Power consumption (sleep)	1.6 W
Power consumption (standby)	6.5 W
Power consumption (average operating)	30 W
Sustainability certificates	Blue Angel, ENERGY STAR
Email protocols	APOP, POP3
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, APOP, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, IPPS, PEAP, SMTP-AUTH, SNMP, SSL/TLS, WPA-PSK, WPA2-PSK
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Mopria Print Service
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Maximum input capacity	500 sheets
Total number of input trays	2
Auto document feeder (ADF) input capacity	50 sheets
Digital sender	-
Maximum duty cycle	- pages per month
Paper tray media types	Plain paper, Thin paper
ISO A-series sizes (A0...A9)	A3, A4
Maximum ISO A-series paper size	A3
Bundled software	Brother Control Center 4 Nuance PaperPort 14
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	398 mm
Width	530 mm
Height	374 mm
