Brother MFC-J5730DW Service Manual

5-22
Confidential
■ Detail description
LCD
Detail description
JB-Can Time
Configure the setting for the time until the host time-out at the Job Cancel. The
setting value is the second time scale.
Sleep Time
Configure the setting for the time until shift to the Sleep Time. Change the setting
of the Function Menu.
Emulation
Configure the setting for the print language. Change the setting of the Function
Menu. When the data includes the ENTER LANGUAGE, the setting becomes
effective. And this setting is ignored.
Auto I/F Time
Configure the setting for the interface release time. The function is in the PC-Print.
When the PC-Scan/Remote-SetUp works on the way, the setting becomes invalid.
Media Type
Configure the setting for the recording paper type. Effective for the print from the
computer. When set the type of the paper on the computer, the setting becomes
effective. And this setting is ignored. The default value is different by the country
setting.
Paper Size
Configure the setting for the drawing size. Does not set the Paper Size of the
Menu, set the drawing size of the PC-Print. When set the size of the paper on the
computer, the setting becomes effective. And this setting is ignored. “Letter” is the
default for the U.S.A. and Canada and “A4” is the default for other countries.
Orientation
Configure the setting for the print direction. Effective for the print from the
computer.
Auto FF
Configure the setting for the ON/OFF of the Auto Form Feed. Effective for the print
from the computer.
Auto FF Time Configure the setting for the TimeOut, when the Auto Form Feed is ON.
Auto LF Configure the setting for the auto line feed.
Auto CR Configure the setting for the auto Carriage Return.
Auto WRAP Configure the setting for the auto CRLF at the print width.
Auto Skip
Configure the setting for the skip at the back-end/tip of the paper and add the
blank space.
Left Margin Configure the setting for the column space at the left end.
Right Margin Configure the setting for the column space at the right end.
Top Margin Configure the setting for the space at the top end.
Bottom Margin Configure the setting for the space at the bottom end.
Lines Configure the setting for the number of the lines in the PCL.
Error Print Configure the setting for the ErrorPrint of the BR-Script3.

Brother MFC-J5730DW Specifications

General

Duplex printing	Yes
Print technology	Inkjet
Maximum resolution	1200 x 4800 DPI
Print speed (ISO/IEC 24734) mono	22 ipm
Print speed (ISO/IEC 24734) color	20 ipm
Time to first page (black, normal)	6 s
Duplex print speed (ISO/IEC 24734) mono	12 ipm
Duplex print speed (ISO/IEC 24734) color	11 ipm
Print speed (black, normal quality, A4/US Letter)	35 ppm
Print speed (color, normal quality, A4/US Letter)	27 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Copy speed (black, normal quality, A4)	12 cpm
Copy speed (color, normal quality, A4)	9 cpm
Scan to	E-mail, E-mail Server, FTP, File, Image, OCR, USB
Scanner type	Flatbed & ADF scanner
Input color depth	48 bit
Maximum scan area	210 x 297 mm
Output color depth	24 bit
Scan speed (color)	14 ppm
Maximum scan resolution	19200 x 19200 DPI
Duplex scan speed (color)	10 ppm
Optical scanning resolution	1200 x 1200 DPI
Faxing	Mono faxing
Fax memory	200 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	100
Display	LCD
Control type	Touch
Product color	Black
Display diagonal	3.66 \
Market positioning	Business
Internal memory	256 MB
Card reader integrated	No
Sound pressure level (printing)	50 dB
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	1
Package depth	469 mm
Package width	639 mm
Package height	511 mm
Package weight	24300 g
Power consumption (off)	0.04 W
Power consumption (sleep)	1.6 W
Power consumption (standby)	6.5 W
Power consumption (average operating)	30 W
Sustainability certificates	Blue Angel, ENERGY STAR
Email protocols	APOP, POP3
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, APOP, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, IPPS, PEAP, SMTP-AUTH, SNMP, SSL/TLS, WPA-PSK, WPA2-PSK
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Mopria Print Service
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Maximum input capacity	500 sheets
Total number of input trays	2
Auto document feeder (ADF) input capacity	50 sheets
Digital sender	-
Maximum duty cycle	- pages per month
Paper tray media types	Plain paper, Thin paper
ISO A-series sizes (A0...A9)	A3, A4
Maximum ISO A-series paper size	A3
Bundled software	Brother Control Center 4 Nuance PaperPort 14
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	398 mm
Width	530 mm
Height	374 mm
