Brother MFC-J5730DW Service Manual

5-31
Confidential
(10)On the test patterns, check the blocks of LF300_1 row. In the same way as in step
(4), enter the number of the block that is the least uneven print and then press the
SET key.
The "LF300_2 NO. +0" appears on the LCD.
(11)In the same way, enter the number of the least uneven block for each of LF300_2
through LF300_4 on the test patterns, and then press the SET key.
The "COR1 NO. +0" appears on the LCD.
(12)On the test patterns, check the blocks of COR1 row. In the same way as in step
(4), enter the number of the block that is the least uneven print and then press the
SET key.
The "COR2 NO. +0" appears on the LCD.
(13)In the same way, enter the number of the least uneven block for each of COR2
through COR6 on the test patterns, and then press the SET key.
Press the X key to return the machine to the initial stage of the maintenance mode.
For the paper feed roller diameter adjustment
(1) Press the 5 and 8 keys in this order in the initial stage of the maintenance mode.
The "Select 58?" appears on the LCD.
(2) Press the Mono Start key.
The "1. ALL" appears on the LCD.
(3) Press the key once.
The "1. PF 2. EXT" appears on the LCD.
(4) Press the 1 key.
The "PF1 NO. +0" appears on the LCD.
(5) On the test patterns, check the blocks of PF1 row. In the same way as in step (4) of
the adjustment of all paper feeding correction values, enter the number of the block
that is the least uneven print and then press the SET key.
(6) In the same way, check the blocks of PF2 through PF6 on the test patterns. Enter
the number of the block that is the least uneven print and press the SET key.
Press the X key to return the machine to the initial stage of the maintenance mode.
For the paper ejection roller diameter adjustment
(1) Press the 5 and 8 keys in this order in the initial stage of the maintenance mode.
The "Select 58?" appears on the LCD.
(2) Press the Mono Start key.
The "1. ALL" appears on the LCD.
(3) Press the key once.
The "1. PF 2. EXT" appears on the LCD.
(4) Press the 2 key.
The "EXT1 NO. +0" appears on the LCD.
(5) On the test patterns, check the blocks of EXT1 row. In the same way as in step (4)
of the adjustment of all paper feeding correction values, enter the number of the
block that is the least uneven print and then press the SET key.
(6) In the same way, on the test patterns, check the blocks of EXT2 through EXT6
respectively. Enter the number of the block that is the least uneven print, and then
press the SET key.
Press the X key to return the machine to the initial stage of the maintenance mode.

Brother MFC-J5730DW Specifications

General

Duplex printing	Yes
Print technology	Inkjet
Maximum resolution	1200 x 4800 DPI
Print speed (ISO/IEC 24734) mono	22 ipm
Print speed (ISO/IEC 24734) color	20 ipm
Time to first page (black, normal)	6 s
Duplex print speed (ISO/IEC 24734) mono	12 ipm
Duplex print speed (ISO/IEC 24734) color	11 ipm
Print speed (black, normal quality, A4/US Letter)	35 ppm
Print speed (color, normal quality, A4/US Letter)	27 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Copy speed (black, normal quality, A4)	12 cpm
Copy speed (color, normal quality, A4)	9 cpm
Scan to	E-mail, E-mail Server, FTP, File, Image, OCR, USB
Scanner type	Flatbed & ADF scanner
Input color depth	48 bit
Maximum scan area	210 x 297 mm
Output color depth	24 bit
Scan speed (color)	14 ppm
Maximum scan resolution	19200 x 19200 DPI
Duplex scan speed (color)	10 ppm
Optical scanning resolution	1200 x 1200 DPI
Faxing	Mono faxing
Fax memory	200 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	100
Display	LCD
Control type	Touch
Product color	Black
Display diagonal	3.66 \
Market positioning	Business
Internal memory	256 MB
Card reader integrated	No
Sound pressure level (printing)	50 dB
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	1
Package depth	469 mm
Package width	639 mm
Package height	511 mm
Package weight	24300 g
Power consumption (off)	0.04 W
Power consumption (sleep)	1.6 W
Power consumption (standby)	6.5 W
Power consumption (average operating)	30 W
Sustainability certificates	Blue Angel, ENERGY STAR
Email protocols	APOP, POP3
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, APOP, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, IPPS, PEAP, SMTP-AUTH, SNMP, SSL/TLS, WPA-PSK, WPA2-PSK
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Mopria Print Service
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Maximum input capacity	500 sheets
Total number of input trays	2
Auto document feeder (ADF) input capacity	50 sheets
Digital sender	-
Maximum duty cycle	- pages per month
Paper tray media types	Plain paper, Thin paper
ISO A-series sizes (A0...A9)	A3, A4
Maximum ISO A-series paper size	A3
Bundled software	Brother Control Center 4 Nuance PaperPort 14
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	398 mm
Width	530 mm
Height	374 mm
