Brother MFC-J5730DW Service Manual

5-70
Confidential
AMS06 (Printing assurance 5)
- Selectors 1 and 2: Improvement of white and black horizontal streaks on
bottom edge of the paper during normal and high-speed
printing on plain paper
Setting these selectors enables improvement of the white and black horizontal
streaks on the bottom edge of paper during normal and high-speed printing on
plain paper.
- Selectors 3 and 4: Improvement of white and black horizontal streaks from
leading edge to center of paper during high-speed and
normal print on plain paper
Setting these selectors enables improvement of the white and black horizontal
streaks from the leading edge to the center of paper during normal and high-
speed printing on plain paper.
- Selectors 5 and 6:
Improvement of white and black horizontal streaks during
print on glossy paper
Setting these selectors enables improvement of the white and black horizontal
streaks during printing on glossy paper.
- Selector 7: Extension of the lower range of printable temperatures
Change the lowest printable temperature from 5 to 0 degree-C.
While switching from "Enable" to "Disable" takes effect without powering OFF
and ON the machine, switching from “Disable” to “Enable” requires powering
OFF and ON to take effect.
Selector
No.
Function Setting and Specifications
1
2
Improvement of white and black
horizontal streaks on bottom
edge of the paper during normal
and high-speed printing on plain
paper
No. 1 2
0 0 : Disable (default)
0 1 : Improve black horizontal streaks
1 0 : Improve white horizontal streaks
1 1 : Further improve black horizontal
streaks
3
4
Improvement of white and black
horizontal streaks from leading
edge to center of paper during
high-speed and normal print on
plain paper
No. 3 4
0 0 : Disable (default)
0 1 : Improve black horizontal streaks
1 0 : Improve white horizontal streaks
1 1 : Further improve black horizontal
streaks
5
6
Improvement of white and black
horizontal streaks during print on
glossy paper
No. 5 6
0 0 : Disable (default)
0 1 : Improve black horizontal streaks
1 0 : Improve white horizontal streaks
1 1 : Further improve black horizontal
streaks
7
Extension of the lower range of
printable temperatures
0: Disable (default) 1: Enable
8
Not used.
