Brother MFC-J5730DW Service Manual

Confidential
2-18
Error Message State
Error
Code
Reference
Jam Front/Rear
Jam Front
Jam Rear
Jam MP Tray
Jam Front/MP Tray
Jam Tray2
Paper Jam
Repeat Jam
Repetitive Paper Jams
Paper jam during duplex-printing
The recording papers are fed in reverse on the
platen when switchback drive is started, triggering
switchback sensor as paper feeding condition.
0D00
2-24
Defective during duplex-printing
Switchback sensor detects paper feed condition at
out of specified timing during switchback.
0E00 2-24
Defective during duplex-printing
Registration sensor detects paper feed condition
at out of specified timing during switchback.
1300 2-25
Paper jam during duplex ejecting
Recording paper is not able to be ejected since it
is longer than 840 mm when ejecting the paper.
1500 2-25
Paper jam during duplex-printing
Registration sensor does not detect paper feed
within specified pulse numbers in the second side
paper re-feed.
1800 2-26
Carriage cannot detect origin.
Detected by the CR encoder sensor.
3100 2-32
Abnormal stop of head/carriage unit being driven
Caused by paper jam when ink is not discharging
3800 2-33
Abnormal stop of head/carriage unit being driven
Caused by paper jam when ink is discharging
3C00 2-34
Paper jam
Paper width sensor cannot detect leading edge or
width of recording papers.
8200 2-45
Paper jam
Registration sensor stays in paper feeding state
even after completion of paper ejection action.
8400 2-45
Paper jam
Switchback sensor stays in paper feeding state
even after completion of paper ejection action.
8700 2-46
Paper jam
Switchback sensor cannot detect paper feeding
state even papers are fed during printing.
8800 2-46
Low Temperature It was detected that the head temperature is the
specified value or less.
4300 2-36
It was detected that the machine temperature is
the specified value or less.
4000 2-35
Media is Full The memory in the media slot is full, or there are
999 or more files.
No Caller ID There is no caller ID information.
No Paper Fed
Repetitive No Paper Fed
It is detected that there is no recording paper in
the valid trays for printing.
--- 4.2.9
Out of Fax Memory
Out of Memory
The memory becomes full. --- 4.10.4

Brother MFC-J5730DW Specifications

General

Duplex printing	Yes
Print technology	Inkjet
Maximum resolution	1200 x 4800 DPI
Print speed (ISO/IEC 24734) mono	22 ipm
Print speed (ISO/IEC 24734) color	20 ipm
Time to first page (black, normal)	6 s
Duplex print speed (ISO/IEC 24734) mono	12 ipm
Duplex print speed (ISO/IEC 24734) color	11 ipm
Print speed (black, normal quality, A4/US Letter)	35 ppm
Print speed (color, normal quality, A4/US Letter)	27 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Copy speed (black, normal quality, A4)	12 cpm
Copy speed (color, normal quality, A4)	9 cpm
Scan to	E-mail, E-mail Server, FTP, File, Image, OCR, USB
Scanner type	Flatbed & ADF scanner
Input color depth	48 bit
Maximum scan area	210 x 297 mm
Output color depth	24 bit
Scan speed (color)	14 ppm
Maximum scan resolution	19200 x 19200 DPI
Duplex scan speed (color)	10 ppm
Optical scanning resolution	1200 x 1200 DPI
Faxing	Mono faxing
Fax memory	200 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	100
Display	LCD
Control type	Touch
Product color	Black
Display diagonal	3.66 \
Market positioning	Business
Internal memory	256 MB
Card reader integrated	No
Sound pressure level (printing)	50 dB
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	1
Package depth	469 mm
Package width	639 mm
Package height	511 mm
Package weight	24300 g
Power consumption (off)	0.04 W
Power consumption (sleep)	1.6 W
Power consumption (standby)	6.5 W
Power consumption (average operating)	30 W
Sustainability certificates	Blue Angel, ENERGY STAR
Email protocols	APOP, POP3
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, APOP, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, IPPS, PEAP, SMTP-AUTH, SNMP, SSL/TLS, WPA-PSK, WPA2-PSK
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Mopria Print Service
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Maximum input capacity	500 sheets
Total number of input trays	2
Auto document feeder (ADF) input capacity	50 sheets
Digital sender	-
Maximum duty cycle	- pages per month
Paper tray media types	Plain paper, Thin paper
ISO A-series sizes (A0...A9)	A3, A4
Maximum ISO A-series paper size	A3
Bundled software	Brother Control Center 4 Nuance PaperPort 14
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	398 mm
Width	530 mm
Height	374 mm
