3 Switching Off and Opening the Instrument Bruker Daltonik GmbH
Figure 3-12 P1 cable detail: left; still connected, right; disconnected
WARNING — DANGEROFELECTRICSHOCK
Before proceeding, make sure that the mains connector is
disconnected to avoid the risk of an electrical shock.
3.4 Components Inside the Source
Figure 3-13 Front view into the source
Page 26 of 44 ultraflex Series Cleaning Manual Revision 2
