Brute FT Series - Page 10

Page 10
Description Diameter
A Air Intake Collar 3˝
B Vent Pipe Collar 3˝
C 'CH' Supply
1
¼˝
D 'CH' Return
1
¼˝
E Gas Inlet 3/4˝
F Condensate Line 1/2˝
9page (199)
16
532.0"
3
7
13
19
A
B
4
11
C
D
E
F
2.0"
2
11
7/8”
5/8”
3/4”
1/2”
5/8”
3/4”
7/8”
1/4”
3/4”
1/4”
TOP VIEW
BOTTOM VIEW
FRONT
VIEW
FTHW
199
Heating only boiler
2.3 Dimensions
