Page 64
5.8 Storage Mode
Storage Mode / Indirect Water Heater
Indicate Indicator
Current CH set point of temperature
Celsius or Fahrenheit
or
If ame detected
Storage mode indication
If there is a Demand for Central Heat (CH)
To change Storage Mode Temp, First turn OFF the power to the Control Display.
Then Press and Hold Button B to get into the Installer Mode.
Rota te Dial E until you nd 25:St Tap Dial E to enter Storage Mode. Storage Mode indicates that the
boiler is heating the water held in an indirect water heater. When Storage Mode is active, the display will
appear as shown.
Turn the E dial clockwise to increase, and counterclockwise to decrease setting.
Press E dial to save changes and to Exit.
NOTE: If using an Aquastat on the indirect tank, the stored hot water temperature is controlled
by the Aquastat.
B
C
E
A
D
To Next Page
