The FT Series, Heating Only, Gas Conversion Kit
pg 4 of 4
Figure E (Conversion label)
14.
Setup your combustion analyzer and place the sensor into the combustion test port
15.
Per Table B for Max Fire
,
change dip switch 6 to ON and 7 to OFF. The unit will cycle up to MAX  re.
16.
WAIT for your combustion analyzer to stabilize. This may take up to 3 minutes depending on your
combustion analyzer. Then measure the CO
2
for MAX  re. Refer to Table D for acceptable MAX  re
combustion readings Do NOT adjust CO2 at MAX Fire. ONLY in MIN Fire, so...
17.
Per Table B for MIN Fire
,
change dip switch 6 to OFF and 7 to ON. The unit will cycle down to MIN Fire.
18.
WAIT for your combustion analyzer to stabilize. Then measure the CO
2
for MIN  re. Refer to Table D for
acceptable MIN  re combustion readings
19.
Open the Gas Valve Adjustment Port by removing the cap screw with a T15 Star/Torx screwdriver.
20.
Then use the T15 Star/Torx to make a minor adjustment (1/8 turn) to either increase or decrease CO
2
.
21.
It may be necessary to go back and forth between HI Fire and LOW Fire several times (and making
adjustments only at LOW Fire), before CO
2
at both are within acceptable levels. Be sure to put the
adjustment port cap screw back onto the valve when done.
22.
Once the CO
2
and manifold pressure measurements for both MIN and MAX Fire are acceptable, set DIP
switches 6 and 7 to the OFF position for Nominal Fire (normal operation).
23.
Write in the correct conversion date and the technicians name to the included gas conversion sticker. See
Figure E. Then apply that sticker adjacent to the rating plate.
24.
Put the boiler cover back on and assemble/tighten the 4 screws that hold the cover in place.
This unit was converted on ____/____/___to _____gas
with kit #____________by______________________
(name and company __________________________
accountable)_________________________________
___________________________________________
Cette unité a été converti ____/____/____ten ______gaz
en utilisant le kit numéro _____ par______________
(nom et société_________________________________
responsable)___________________________________
_____________________________________________
H22415900
Manifold pressure Propane Gas (LP) Natural Gas (NG)
MFTHW 100
-0.075 ˝ WC -0.070 ˝ WC
-0.003 ˝ WC -0.000 ˝ WC
MFTHW 140
-0.130 ˝ WC -0.100 ˝ WC
-0.004 ˝ WC -0.002 ˝ WC
MFTHW 175
-0.169 ˝ WC -0.129 ˝ WC
-0.015 ˝ WC -0.015 ˝ WC
MFTHW 199
-0.169 ˝ WC -0.129 ˝ WC
-0.015 ˝ WC -0.015 ˝ WC
CO
2
value
Propane Gas (LP) Natural Gas (NG)
2˝ VENT 3˝ VENT 2˝ VENT 3˝ VENT
MFTHW 80/100
120/140/175/199
9.5~11% 8.5~10.5%
9~10.5 % 8~10%
Refer to the below table.
Table D
All sizes
(and all altitudes)
