17
PERFORMANCE DATA (cont)
COMBINATION RATINGS (cont)
UNIT 569D072 (cont)
LEGEND
*This combination is E
NERGY STA R ® compliant.
569D072/524A-C090 WITH HIGH-CAPACITY 4-ROW COIL*
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
2400 3000 3750
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 71.9 72.9 78.3 84.8 77.7 77.7 81.3 87.6 81.6 81.6 83.4 89.4
SHC 71.9 69.5 57.7 45.1 77.7 77.7 67.0 50.9 81.6 81.6 75.2 56.4
kW 4.55 4.57 4.67 4.79 4.66 4.66 4.73 4.85 4.73 4.73 4.77 4.89
85
TC 70.9 71.7 76.9 83.3 76.5 76.5 79.8 86.1 80.3 80.3 81.9 87.8
SHC 70.9 68.8 57.2 44.6 76.5 76.5 66.4 50.3 80.3 80.3 74.6 55.9
kW 4.83 4.84 4.94 5.07 4.93 4.93 5.00 5.12 5.01 5.01 5.04 5.16
95
TC 68.8 69.3 74.2 80.4 74.1 74.1 76.9 82.9 77.7 77.8 79.0 84.5
SHC 68.8 67.5 56.1 43.5 74.1 74.1 65.2 49.3 77.7 77.8 73.3 54.8
kW 5.37 5.38 5.48 5.61 5.48 5.48 5.54 5.66 5.55 5.56 5.58 5.70
100
TC 67.7 68.0 72.8 78.8 72.8 72.9 75.4 81.3 76.4 76.4 77.4 82.8
SHC 67.7 66.8 55.5 43.0 72.8 72.9 64.6 48.8 76.4 76.4 72.5 54.3
kW 5.68 5.69 5.79 5.92 5.79 5.79 5.85 5.97 5.87 5.87 5.89 6.01
105
TC 66.5 66.8 71.3 77.3 71.6 71.6 73.9 79.6 75.0 75.0 75.9 81.1
SHC 66.5 66.0 54.9 42.5 71.6 71.6 64.0 48.2 75.0 75.0 71.8 53.7
kW 5.99 6.00 6.09 6.23 6.10 6.10 6.15 6.28 6.18 6.18 6.20 6.32
115
TC 64.3 64.3 68.4 74.2 69.0 69.1 70.8 76.2 72.3 72.3 72.7 77.7
SHC 64.3 64.3 53.8 41.4 69.0 69.1 62.8 47.1 72.3 72.3 70.3 52.6
kW 6.61 6.61 6.71 6.85 6.73 6.73 6.77 6.90 6.81 6.8 6.81 6.94
569D072/524A-B090 WITH STANDARD 3-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
2400 3000 3750
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 68.4 69.5 74.8 81.0 73.6 73.6 77.6 83.8 77.3 77.3 79.5 85.5
SHC 68.4 65.8 54.8 42.9 73.6 73.6 63.1 48.1 77.3 77.3 70.4 52.9
kW 4.49 4.51 4.61 4.72 4.58 4.58 4.65 4.77 4.65 4.65 4.69 4.81
85
TC 67.4 68.4 73.6 79.7 72.6 72.6 76.3 82.4 76.1 76.1 78.2 84.0
SHC 67.4 65.2 54.3 42.4 72.6 72.6 62.6 47.6 76.1 76.1 69.8 52.4
kW 4.76 4.78 4.88 5.00 4.86 4.86 4.93 5.05 4.92 4.92 4.96 5.08
95
TC 65.5 66.2 71.1 77.1 70.4 70.5 73.7 79.5 73.8 73.8 75.5 81.1
SHC 65.5 64.0 53.3 41.5 70.4 70.5 61.5 46.6 73.8 73.8 68.7 51.4
kW 5.31 5.32 5.42 5.54 5.40 5.40 5.47 5.59 5.47 5.47 5.51 5.62
100
TC 64.5 65.1 69.7 75.6 69.3 69.3 72.3 78.0 72.6 72.6 74.0 79.5
SHC 64.5 63.3 52.8 41.0 69.3 69.3 60.9 46.1 72.6 72.6 68.0 50.9
kW 5.62 5.63 5.72 5.85 5.71 5.72 5.78 5.90 5.78 5.78 5.82 5.93
105
TC 63.4 63.9 68.4 74.1 68.1 68.1 70.9 76.5 71.4 71.4 72.6 77.9
SHC 63.4 62.5 52.2 40.5 68.1 68.1 60.4 45.6 71.4 71.4 67.3 50.4
kW 5.93 5.94 6.03 6.16 6.03 6.03 6.08 6.21 6.10 6.10 6.12 6.24
115
TC 61.4 61.6 65.8 71.2 65.9 65.8 68.0 73.4 68.9 68.9 69.7 74.8
SHC 61.4 61.1 51.2 39.4 65.9 65.8 59.2 44.6 68.9 68.9 66.0 49.4
kW 6.55 6.55 6.64 6.78 6.65 6.65 6.70 6.83 6.72 6.73 6.74 6.86
Edb — Entering Dry Bulb
Ewb — Entering Wet Bulb
kW—Compressor Motor Power Input
SHC — Sensible Heat Capacity (1000 Btuh) Gross
TC — Total Capacity (1000 Btuh) Gross
50TFQ004-012
569D072-120, 576C120, 569F120
