18
PERFORMANCE DATA (cont)
COMBINATION RATINGS (cont)
UNIT 569D090
LEGEND
*This combination is E
NERGY STA R ® compliant.
569D090/524A-C072 WITH HIGH-CAPACITY 4-ROW COIL*
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
1800 2400 3000
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 78.9 85.1 92.8 101.0 87.0 90.7 98.3 106.0 93.0 94.7 102.0 110.0
SHC 77.9 69.0 59.0 48.7 87.0 79.9 66.9 53.6 93.0 89.3 74.2 58.0
kW 5.75 5.78 5.85 5.94 5.79 5.83 5.91 6.01 5.85 5.87 5.96 6.06
85
TC 77.6 83.6 91.3 99.3 85.7 89.2 96.6 105.0 91.6 93.1 100.0 108.0
SHC 77.0 68.3 58.3 48.0 85.7 79.1 66.3 52.9 91.6 88.4 73.5 57.4
kW 6.10 6.13 6.20 6.30 6.14 6.18 6.26 6.37 6.20 6.22 6.31 6.41
95
TC 75.1 80.8 88.3 96.1 83.2 86.1 93.3 101.0 88.9 89.9 96.5 104.0
SHC 75.1 66.8 56.9 46.7 83.2 77.6 64.9 51.6 88.9 86.7 72.2 56.1
kW 6.80 6.82 6.90 7.00 6.85 6.87 6.96 7.08 6.91 6.92 7.01 7.12
100
TC 73.9 79.2 86.6 94.4 81.8 84.4 91.4 99.2 87.4 88.2 94.5 102.0
SHC 73.8 66.0 56.2 46.1 81.8 76.7 64.1 50.9 87.4 85.7 71.4 55.3
kW 7.20 7.21 7.29 7.40 7.24 7.26 7.36 7.47 7.30 7.31 7.40 7.52
105
TC 72.6 77.6 85.0 92.6 80.4 82.7 89.6 97.3 85.9 86.5 92.6 100.0
SHC 72.6 65.3 55.5 45.4 80.4 75.9 63.4 50.2 85.9 84.7 70.7 54.6
kW 7.59 7.60 7.68 7.79 7.64 7.66 7.75 7.87 7.70 7.71 7.80 7.92
115
TC 70.1 74.5 81.7 89.1 77.7 79.4 86.0 93.5 82.9 83.1 88.8 96.2
SHC 70.1 63.7 54.0 44.0 77.7 74.3 61.9 48.8 82.9 82.7 69.2 53.2
kW 8.38 8.38 8.47 8.58 8.43 8.44 8.53 8.66 8.48 8.49 8.58 8.71
569D090/524A-B072 WITH STANDARD 3-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
1800 2400 3000
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 75.3 81.2 88.5 96.1 82.5 86.4 93.6 101.0 88.0 89.9 96.8 104.0
SHC 74.3 65.8 56.3 46.4 82.5 75.7 63.5 50.9 88.0 84.1 70.0 54.9
kW 5.77 5.82 5.91 6.00 5.84 5.88 5.97 6.07 5.90 5.93 6.01 6.12
85
TC 74.2 79.8 87.1 94.6 81.3 84.9 92.0 99.5 86.7 88.4 95.2 103.0
SHC 73.4 65.2 55.6 45.8 81.3 75.0 62.8 50.2 86.7 83.3 69.4 54.3
kW 6.12 6.18 6.27 6.37 6.20 6.24 6.33 6.44 6.26 6.28 6.38 6.48
95
TC 71.8 77.2 84.2 91.6 79.0 82.0 88.8 96.2 84.1 85.4 91.9 99.2
SHC 71.6 63.8 54.3 44.6 79.0 73.6 61.5 49.0 84.1 81.7 68.1 53.0
kW 6.83 6.89 6.98 7.10 6.91 6.95 7.05 7.17 6.99 7.00 7.10 7.22
100
TC 70.6 75.7 82.6 89.9 77.7 80.4 87.1 94.4 82.7 83.8 90.0 97.3
SHC 70.5 63.1 53.6 43.9 77.7 72.8 60.8 48.3 82.7 80.7 67.4 52.3
kW 7.22 7.28 7.38 7.50 7.31 7.35 7.45 7.58 7.39 7.40 7.51 7.63
105
TC 69.4 74.2 81.1 88.3 76.4 78.8 85.4 92.6 81.3 82.2 88.2 95.4
SHC 69.4 62.4 53.0 43.3 76.4 72.0 60.1 47.7 81.3 79.8 66.7 51.7
kW 7.61 7.67 7.78 7.91 7.70 7.75 7.86 7.99 7.79 7.80 7.91 8.04
115
TC 67.0 71.3 78.0 85.0 73.8 75.6 82.0 89.0 78.5 78.9 84.6 91.7
SHC 67.0 60.9 51.6 41.9 73.8 70.5 58.7 46.4 78.5 77.9 65.3 50.3
kW 8.39 8.45 8.59 8.73 8.49 8.54 8.66 8.80 8.59 8.60 8.71 8.86
Edb — Entering Dry Bulb
Ewb — Entering Wet Bulb
kW—Compressor Motor Power Input
SHC — Sensible Heat Capacity (1000 Btuh) Gross
TC — Total Capacity (1000 Btuh) Gross
50TFQ004-012
569D072-120, 576C120, 569F120
