PERFORMANCE DATA (cont)
COMBINATION RATINGS (cont)
UNIT 569D090 (cont)
LEGEND
*This combination is E
NERGY STA R ® compliant.
569D090/524A-C090 WITH HIGH-CAPACITY 4-ROW COIL*
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
2205 3000 3750
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 86.0 90.4 98.0 106.0 94.1 95.7 103.0 111.0 96.9 97.8 104.0 112.0
SHC 86.0 78.0 65.6 52.8 94.1 90.3 75.0 58.5 96.9 94.8 79.3 61.1
kW 5.78 5.83 5.91 6.01 5.86 5.88 5.97 6.07 5.90 5.91 5.98 6.09
85
TC 84.8 88.9 96.4 104.0 92.7 94.1 101.0 109.0 95.4 96.2 102.0 110.0
SHC 84.8 77.3 64.9 52.2 92.7 89.4 74.2 57.8 95.4 93.7 78.5 60.5
kW 6.14 6.18 6.26 6.37 6.22 6.23 6.32 6.42 6.25 6.26 6.34 6.44
95
TC 82.3 85.8 93.1 101.0 90.0 90.9 97.3 105.0 92.6 93.1 98.7 106.0
SHC 82.3 75.8 63.5 50.9 90.0 87.7 72.8 56.5 92.6 91.4 77.1 59.2
kW 6.85 6.88 6.96 7.07 6.92 6.93 7.02 7.13 6.96 6.96 7.04 7.15
100
TC 81.0 84.2 91.3 99.1 88.5 89.2 95.4 103.0 91.0 91.4 96.8 104.0
SHC 81.0 75.0 62.8 50.2 88.5 86.7 72.1 55.8 91.0 90.1 76.4 58.5
kW 7.24 7.26 7.36 7.47 7.32 7.33 7.41 7.53 7.35 7.36 7.43 7.55
105
TC 79.6 82.5 89.6 97.2 87.0 87.5 93.5 101.0 89.5 89.7 94.9 102.0
SHC 79.6 74.1 62.1 49.5 87.0 85.7 71.4 55.2 89.5 88.8 75.6 57.8
kW 7.63 7.65 7.75 7.87 7.71 7.72 7.81 7.93 7.75 7.75 7.83 7.95
115
TC 77.0 79.2 86.0 93.5 83.9 84.1 89.8 97.2 86.3 86.4 91.0 98.3
SHC 77.0 72.5 60.6 48.1 83.9 83.7 69.9 53.8 86.3 86.2 74.1 56.4
kW 8.41 8.42 8.53 8.66 8.50 8.50 8.60 8.73 8.54 8.54 8.62 8.75
569D090/524A-B090 WITH STANDARD 3-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
2205 3000 3750
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 81.7 85.9 93.2 101.0 89.0 90.8 97.5 105.0 91.6 92.6 98.8 106.0
SHC 81.7 74.2 62.4 50.2 89.0 85.2 70.9 55.4 91.6 89.4 74.7 57.7
kW 5.83 5.88 5.97 6.07 5.92 5.94 6.02 6.12 5.95 5.96 6.04 6.14
85
TC 80.6 84.5 91.6 99.2 87.7 89.3 95.8 103.0 90.2 91.1 97.1 105.0
SHC 80.6 73.5 61.7 49.6 87.7 84.5 70.2 54.8 90.2 88.4 74.1 57.1
kW 6.19 6.23 6.33 6.43 6.28 6.30 6.39 6.49 6.31 6.32 6.40 6.51
95
TC 78.3 81.7 88.5 95.9 85.2 86.3 92.5 99.9 87.6 88.2 93.8 101.0
SHC 78.3 72.1 60.4 48.4 85.2 82.9 69.0 53.6 87.6 86.4 72.8 55.9
kW 6.90 6.95 7.05 7.17 7.00 7.02 7.11 7.23 7.04 7.05 7.13 7.25
100
TC 77.0 80.1 86.9 94.2 83.7 84.7 90.7 98.0 86.1 86.6 91.9 99.1
SHC 77.0 71.3 59.8 47.7 83.7 81.9 68.3 52.9 86.1 85.2 72.1 55.2
kW 7.30 7.34 7.45 7.57 7.40 7.42 7.52 7.64 7.44 7.45 7.54 7.66
105
TC 75.7 78.6 85.2 92.4 82.3 83.0 88.9 96.1 84.6 85.0 90.1 97.2
SHC 75.7 70.6 59.1 47.0 82.3 80.9 67.6 52.2 84.6 83.9 71.4 54.6
kW 7.69 7.74 7.86 7.98 7.80 7.82 7.92 8.05 7.84 7.85 7.94 8.07
115
TC 73.2 75.4 81.9 88.8 79.5 79.8 85.3 92.3 81.7 81.8 86.4 93.3
SHC 73.2 69.0 57.7 45.7 79.5 79.0 66.1 50.9 81.7 81.4 70.0 53.2
kW 8.48 8.53 8.67 8.79 8.61 8.61 8.73 8.87 8.65 8.65 8.75 8.89
Edb — Entering Dry Bulb
Ewb — Entering Wet Bulb
kW—Compressor Motor Power Input
SHC — Sensible Heat Capacity (1000 Btuh) Gross
TC — Total Capacity (1000 Btuh) Gross
