20
PERFORMANCE DATA (cont)
COMBINATION RATINGS (cont)
UNIT 569D120
LEGEND
569D120/524A-C120 WITH HIGH-CAPACITY 4-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
3000 4000 5000
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 117.0 122.0 132.0 142.0 127.0 129.0 138.0 148.0 134.0 134.0 141.0 151.0
SHC 117.0 106.0 88.4 70.9 127.0 122.0 101.0 78.6 134.0 134.0 113.0 85.9
kW 8.34 8.48 8.74 9.02 8.61 8.66 8.89 9.18 8.81 8.80 9.00 9.28
85
TC 115.0 120.0 129.0 140.0 125.0 127.0 135.0 145.0 132.0 132.0 139.0 148.0
SHC 115.0 104.0 87.5 70.0 125.0 121.0 100.0 77.6 132.0 132.0 112.0 84.9
kW 8.72 8.85 9.11 9.40 8.99 9.04 9.27 9.56 9.19 9.19 9.38 9.67
95
TC 112.0 116.0 125.0 135.0 121.0 122.0 130.0 140.0 128.0 128.0 134.0 143.0
SHC 112.0 102.0 85.5 68.2 121.0 119.0 98.2 75.8 128.0 128.0 110.0 83.1
kW 9.49 9.60 9.86 10.20 9.76 9.79 10.00 10.30 9.96 9.95 10.10 10.40
100
TC 110.0 113.0 122.0 132.0 119.0 120.0 127.0 137.0 125.0 125.0 131.0 140.0
SHC 110.0 101.0 84.4 67.1 119.0 117.0 97.1 74.8 125.0 125.0 109.0 82.1
kW 9.90 10.00 10.30 10.60 10.20 10.20 10.40 10.70 10.40 10.40 10.50 10.80
105
TC 108.0 111.0 120.0 129.0 117.0 117.0 125.0 134.0 123.0 123.0 128.0 137.0
SHC 108.0 100.0 83.3 66.1 117.0 116.0 96.0 73.7 123.0 123.0 108.0 81.0
kW 10.30 10.40 10.70 11.00 10.60 10.60 10.80 11.10 10.80 10.80 10.90 11.20
115
TC 104.0 106.0 114.0 124.0 112.0 112.0 119.0 128.0 118.0 118.0 122.0 131.0
SHC 104.0 97.7 81.2 64.0 112.0 112.0 93.8 71.7 118.0 118.0 105.0 78.9
kW 11.10 11.20 11.50 11.70 11.40 11.40 11.60 11.90 11.60 11.60 11.70 12.00
569D120/524A-B120 WITH STANDARD 3-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
3000 4000 5000
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 110.0 115.0 124.0 134.0 119.0 121.0 130.0 139.0 126.0 126.0 133.0 143.0
SHC 110.0 99.4 83.3 66.8 119.0 114.0 94.6 73.6 126.0 125.0 105.0 79.9
kW 8.19 8.32 8.55 8.82 8.41 8.48 8.70 8.96 8.59 8.60 8.80 9.06
85
TC 108.0 113.0 122.0 132.0 117.0 119.0 128.0 137.0 124.0 124.0 131.0 140.0
SHC 108.0 98.4 82.4 66.0 117.0 113.0 93.7 72.8 124.0 123.0 104.0 79.0
kW 8.57 8.70 8.93 9.20 8.80 8.85 9.08 9.35 8.97 8.98 9.17 9.44
95
TC 105.0 110.0 118.0 127.0 114.0 115.0 123.0 132.0 120.0 120.0 126.0 135.0
SHC 105.0 96.6 80.7 64.3 114.0 111.0 91.9 71.1 120.0 120.0 102.0 77.3
kW 9.34 9.45 9.69 9.96 9.57 9.61 9.83 10.10 9.73 9.74 9.93 10.20
100
TC 104.0 107.0 116.0 125.0 112.0 113.0 121.0 130.0 118.0 118.0 124.0 132.0
SHC 104.0 95.5 79.7 63.4 112.0 109.0 90.9 70.2 118.0 118.0 101.0 76.4
kW 9.76 9.86 10.10 10.40 9.98 10.00 10.20 10.50 10.10 10.10 10.30 10.60
105
TC 102.0 105.0 114.0 122.0 110.0 111.0 118.0 127.0 116.0 116.0 121.0 130.0
SHC 102.0 94.4 78.7 62.4 110.0 108.0 89.9 69.2 116.0 116.0 100.0 75.5
kW 10.20 10.30 10.5 10.80 10.40 10.40 10.60 10.90 10.60 10.60 10.70 11.00
115
TC 98.4 101.0 109.0 117.0 106.0 106.0 113.0 122.0 111.0 111.0 116.0 124.0
SHC 98.4 92.2 76.7 60.5 106.0 105.0 87.8 67.3 111.0 111.0 97.9 73.6
kW 11.00 11.10 11.30 11.60 11.20 11.20 11.40 11.70 11.40 11.40 11.50 11.80
Edb — Entering Dry Bulb
Ewb — Entering Wet Bulb
kW—Compressor Motor Power Input
SHC — Sensible Heat Capacity (1000 Btuh) Gross
TC — Total Capacity (1000 Btuh) Gross
50TFQ004-012
569D072-120, 576C120, 569F120
