PERFORMANCE DATA (cont)
COMBINATION RATINGS (cont)
UNIT 569D120 (cont)
LEGEND
569D120/524A-C150 WITH HIGH-CAPACITY 4-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
3750 5000 6250
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 126.0 129.0 138.0 149.0 136.0 136.0 143.0 153.0 142.0 142.0 147.0 156.0
SHC 126.0 119.0 98.7 77.4 136.0 135.0 114.0 86.5 142.0 142.0 127.0 95.0
kW 8.60 8.68 8.94 9.23 8.87 8.87 9.08 9.37 9.06 9.05 9.18 9.46
85
TC 124.0 127.0 136.0 146.0 134.0 134.0 141.0 151.0 140.0 140.0 144.0 154.0
SHC 124.0 118.0 97.7 76.5 134.0 133.0 113.0 85.6 140.0 140.0 126.0 94.1
kW 8.98 9.05 9.31 9.61 9.25 9.25 9.46 9.76 9.44 9.44 9.56 9.84
95
TC 120.0 122.0 131.0 141.0 129.0 129.0 136.0 145.0 136.0 136.0 139.0 148.0
SHC 120.0 116.0 95.7 74.6 129.0 129.0 111.0 83.8 136.0 136.0 124.0 92.3
kW 9.74 9.80 10.10 10.40 10.00 10.00 10.20 10.50 10.20 10.20 10.30 10.60
100
TC 118.0 120.0 128.0 138.0 127.0 127.0 133.0 142.0 133.0 133.0 136.0 145.0
SHC 118.0 114.0 94.6 73.6 127.0 127.0 109.0 82.7 133.0 133.0 123.0 91.2
kW 10.20 10.20 10.50 10.80 10.40 10.40 10.60 10.90 10.60 10.60 10.70 11.00
105
TC 116.0 117.0 126.0 135.0 125.0 125.0 130.0 139.0 130.0 130.0 133.0 142.0
SHC 116.0 113.0 93.5 72.6 125.0 125.0 108.0 81.6 130.0 130.0 121.0 90.1
kW 10.60 10.60 10.90 11.20 10.80 10.80 11.00 11.30 11.00 11.00 11.10 11.40
115
TC 112.0 112.0 120.0 129.0 120.0 120.0 124.0 133.0 125.0 125.0 127.0 135.0
SHC 112.0 110.0 91.4 70.5 120.0 120.0 106.0 79.5 125.0 125.0 119.0 87.9
kW 11.40 11.40 11.70 12.00 11.60 11.70 11.80 12.10 11.80 11.80 11.90 12.20
569D120/524A-B150 WITH STANDARD 3-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
3750 5000 6250
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 119.0 123.0 132.0 142.0 128.0 129.0 137.0 147.0 135.0 135.0 140.0 150.0
SHC 119.0 112.0 93.2 73.4 128.0 127.0 106.0 81.4 135.0 135.0 118.0 88.6
kW 8.42 8.51 8.77 9.05 8.66 8.68 8.90 9.18 8.84 8.84 8.99 9.27
85
TC 118.0 121.0 130.0 140.0 126.0 127.0 135.0 144.0 133.0 133.0 138.0 147.0
SHC 118.0 111.0 92.3 72.5 126.0 126.0 105.0 80.5 133.0 133.0 117.0 87.8
kW 8.80 8.89 9.14 9.43 9.05 9.06 9.28 9.56 9.22 9.22 9.37 9.65
95
TC 114.0 116.0 125.0 135.0 122.0 123.0 130.0 139.0 128.0 128.0 133.0 142.0
SHC 114.0 109.0 90.4 70.7 122.0 122.0 103.0 78.7 128.0 128.0 115.0 86.0
kW 9.57 9.64 9.89 10.20 9.81 9.81 10.00 10.30 9.99 9.99 10.10 10.40
100
TC 112.0 114.0 123.0 132.0 120.0 120.0 127.0 136.0 126.0 126.0 130.0 139.0
SHC 112.0 108.0 89.3 69.7 120.0 120.0 102.0 77.7 126.0 126.0 114.0 85.0
kW 9.98 10.00 10.30 10.60 10.20 10.20 10.40 10.70 10.40 10.40 10.50 10.80
105
TC 110.0 112.0 120.0 129.0 118.0 118.0 124.0 133.0 123.0 123.0 127.0 136.0
SHC 110.0 106.0 88.2 68.7 118.0 118.0 101.0 76.7 123.0 123.0 113.0 84.0
kW 10.40 10.40 10.70 11.00 10.60 10.60 10.80 11.10 10.80 10.80 10.90 11.20
115
TC 106.0 107.0 115.0 124.0 114.0 113.0 119.0 127.0 119.0 119.0 121.0 130.0
SHC 106.0 104.0 86.1 66.6 114.0 113.0 99.1 74.6 119.0 119.0 110.0 81.9
kW 11.20 11.20 11.50 11.80 11.40 11.40 11.60 11.90 11.60 11.60 11.70 12.00
Edb — Entering Dry Bulb
Ewb — Entering Wet Bulb
kW—Compressor Motor Power Input
SHC — Sensible Heat Capacity (1000 Btuh) Gross
TC — Total Capacity (1000 Btuh) Gross
50TFQ004-012
569D072-120, 576C120, 569F120
