22
PERFORMANCE DATA (cont)
COMBINATION RATINGS (cont)
UNIT 576C120
LEGEND
576C120/524A-C120 WITH HIGH-CAPACITY 4-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
3000 4000 5000
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 113.0 118.0 129.0 141.0 124.0 126.0 135.0 147.0 132.0 132.0 139.0 151.0
SHC 113.0 104.0 87.4 70.5 124.0 121.0 101.0 78.8 132.0 132.0 113.0 86.6
kW 8.00 8.12 8.35 8.61 8.26 8.29 8.49 8.75 8.43 8.43 8.58 8.82
85
TC 111.0 115.0 126.0 137.0 122.0 123.0 132.0 144.0 129.0 129.0 136.0 148.0
SHC 111.0 102.0 86.1 69.3 122.0 119.0 99.5 77.6 129.0 129.0 112.0 85.4
kW 8.39 8.51 8.76 9.05 8.67 8.69 8.91 9.20 8.86 8.86 9.01 9.28
95
TC 106.0 110.0 120.0 131.0 117.0 117.0 125.0 137.0 124.0 124.0 129.0 140.0
SHC 106.0 99.8 83.7 66.9 117.0 116.0 96.9 75.1 124.0 124.0 109.0 82.9
kW 9.17 9.28 9.58 9.93 9.49 9.51 9.76 10.10 9.72 9.72 9.88 10.20
100
TC 104.0 107.0 117.0 128.0 114.0 114.0 122.0 133.0 121.0 121.0 126.0 137.0
SHC 104.0 98.4 82.4 65.7 114.0 114.0 95.6 73.9 121.0 121.0 108.0 81.7
kW 9.55 9.65 9.98 10.40 9.90 9.90 10.20 10.50 10.10 10.10 10.30 10.60
105
TC 102.0 104.0 114.0 124.0 112.0 112.0 119.0 130.0 118.0 118.0 122.0 133.0
SHC 102.0 97.0 81.1 64.5 112.0 112.0 94.3 72.7 118.0 118.0 106.0 80.5
kW 9.93 10.00 10.40 10.80 10.30 10.30 10.60 11.00 10.60 10.60 10.70 11.10
115
TC 97.2 98.6 107.0 118.0 106.0 106.0 112.0 122.0 113.0 113.0 116.0 125.0
SHC 97.2 94.2 78.6 62.1 106.0 106.0 91.7 70.2 113.0 113.0 104.0 78.0
kW 10.70 10.80 11.20 11.60 11.10 11.10 11.40 11.80 11.40 11.40 11.50 12.00
576C120/524A-B120 WITH STANDARD 3-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
3000 4000 5000
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 107.0 112.0 123.0 134.0 118.0 119.0 129.0 140.0 125.0 125.0 133.0 144.0
SHC 107.0 98.8 83.3 67.2 118.0 114.0 95.5 74.8 125.0 125.0 107.0 81.8
kW 7.91 8.03 8.25 8.49 8.14 8.18 8.38 8.62 8.30 8.30 8.46 8.71
85
TC 105.0 110.0 120.0 131.0 115.0 117.0 126.0 137.0 122.0 122.0 129.0 141.0
SHC 105.0 97.5 82.2 66.1 115.0 113.0 94.3 73.7 122.0 122.0 105.0 80.6
kW 8.29 8.40 8.65 8.92 8.54 8.57 8.79 9.06 8.71 8.71 8.88 9.15
95
TC 101.0 105.0 114.0 125.0 111.0 111.0 120.0 131.0 117.0 117.0 123.0 134.0
SHC 101.0 95.0 79.8 63.9 111.0 109.0 92.0 71.4 117.0 117.0 103.0 78.4
kW 9.04 9.15 9.44 9.78 9.34 9.36 9.61 9.94 9.54 9.54 9.72 10.00
100
TC 98.9 102.0 111.0 122.0 108.0 109.0 117.0 127.0 115.0 115.0 120.0 131.0
SHC 98.9 93.7 78.7 62.8 108.0 108.0 90.8 70.3 115.0 115.0 102.0 77.3
kW 9.41 9.51 9.83 10.20 9.73 9.74 10.00 10.40 9.94 9.95 10.10 10.50
105
TC 96.8 99.4 108.0 119.0 106.0 106.0 113.0 124.0 112.0 112.0 117.0 127.0
SHC 96.8 92.3 77.5 61.6 106.0 106.0 89.5 69.2 112.0 112.0 100.0 76.1
kW 9.78 9.87 10.0 10.60 10.10 10.10 10.40 10.80 10.30 10.30 10.50 10.90
115
TC 92.5 94.1 103.0 113.0 101.0 101.0 107.0 117.0 107.0 107.0 110.0 120.0
SHC 92.5 89.7 75.1 59.4 101.0 101.0 87.1 67.0 107.0 107.0 97.7 73.9
kW 10.50 10.60 11.00 11.40 10.90 10.90 11.20 11.60 11.20 11.20 11.30 11.80
Edb — Entering Dry Bulb
Ewb — Entering Wet Bulb
kW—Compressor Motor Power Input
SHC — Sensible Heat Capacity (1000 Btuh) Gross
TC — Total Capacity (1000 Btuh) Gross
50TFQ004-012
569D072-120, 576C120, 569F120
