PERFORMANCE DATA (cont)
COMBINATION RATINGS (cont)
UNIT 576C120 (cont)
LEGEND
576C120/524A-C150 WITH HIGH-CAPACITY 4-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
3750 5000 6250
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 122.0 125.0 135.0 147.0 133.0 133.0 141.0 153.0 141.0 141.0 145.0 157.0
SHC 122.0 117.0 97.7 77.1 133.0 133.0 113.0 86.9 141.0 141.0 127.0 96.0
kW 8.23 8.28 8.51 8.77 8.47 8.47 8.64 8.88 8.62 8.62 8.72 8.95
85
TC 120.0 122.0 132.0 144.0 130.0 130.0 138.0 149.0 138.0 138.0 142.0 153.0
SHC 120.0 116.0 96.5 76.0 130.0 130.0 112.0 85.6 138.0 138.0 126.0 94.7
kW 8.64 8.69 8.94 9.22 8.90 8.90 9.07 9.35 9.07 9.07 9.16 9.42
95
TC 115.0 116.0 126.0 137.0 125.0 125.0 131.0 142.0 132.0 132.0 135.0 145.0
SHC 115.0 113.0 93.9 73.6 125.0 125.0 109.0 83.2 132.0 132.0 123.0 92.3
kW 9.46 9.50 9.78 10.10 9.76 9.76 9.95 10.30 9.97 9.97 10.10 10.40
100
TC 113.0 113.0 123.0 134.0 122.0 122.0 128.0 139.0 129.0 129.0 131.0 141.0
SHC 113.0 111.0 92.6 72.4 122.0 122.0 108.0 82.0 129.0 129.0 121.0 91.1
kW 9.86 9.89 10.20 10.60 10.20 10.20 10.40 10.70 10.40 10.40 10.50 10.80
105
TC 110.0 111.0 119.0 130.0 119.0 119.0 124.0 135.0 126.0 126.0 128.0 138.0
SHC 110.0 109.0 91.4 71.1 119.0 119.0 107.0 80.8 126.0 126.0 120.0 89.9
kW 10.30 10.30 10.60 11.00 10.60 10.60 10.80 11.20 10.80 10.80 10.90 11.30
115
TC 105.0 105.0 113.0 123.0 114.0 114.0 117.0 127.0 120.0 120.0 121.0 130.0
SHC 105.0 105.0 88.8 68.7 114.0 114.0 104.0 78.4 120.0 120.0 117.0 87.4
kW 11.10 11.10 11.40 11.90 11.50 11.50 11.60 12.10 11.70 11.70 11.80 12.20
576C120/524A-B150 WITH STANDARD 3-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
3750 5000 6250
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 115.0 118.0 129.0 140.0 125.0 126.0 134.0 146.0 132.0 132.0 138.0 149.0
SHC 115.0 110.0 92.3 73.1 125.0 125.0 106.0 81.7 132.0 132.0 119.0 89.6
kW 8.08 8.14 8.37 8.62 8.30 8.30 8.48 8.74 8.45 8.45 8.57 8.81
85
TC 113.0 116.0 126.0 137.0 123.0 123.0 131.0 142.0 130.0 130.0 134.0 146.0
SHC 113.0 109.0 91.1 71.9 123.0 123.0 105.0 80.5 130.0 130.0 117.0 88.5
kW 8.47 8.53 8.78 9.06 8.71 8.72 8.91 9.18 8.88 8.88 8.99 9.26
95
TC 109.0 110.0 120.0 131.0 118.0 118.0 124.0 136.0 124.0 124.0 128.0 139.0
SHC 109.0 106.0 88.7 69.6 118.0 118.0 102.0 78.2 124.0 124.0 114.0 86.1
kW 9.25 9.31 9.60 9.94 9.54 9.54 9.75 10.10 9.73 9.74 9.85 10.20
100
TC 106.0 108.0 116.0 127.0 115.0 115.0 121.0 132.0 121.0 121.0 124.0 135.0
SHC 106.0 104.0 87.5 68.5 115.0 115.0 101.0 77.0 121.0 121.0 113.0 84.9
kW 9.64 9.68 9.99 10.40 9.95 9.95 10.10 10.50 10.20 10.20 10.30 10.60
105
TC 104.0 105.0 113.0 124.0 112.0 113.0 118.0 129.0 118.0 118.0 121.0 131.0
SHC 104.0 103.0 86.2 67.3 112.0 113.0 99.7 75.8 118.0 118.0 111.0 83.8
kW 10.00 10.10 10.40 10.80 10.40 10.40 10.60 10.90 10.60 10.60 10.70 11.00
115
TC 99.2 99.3 107.0 117.0 107.0 107.0 111.0 121.0 113.0 113.0 114.0 124.0
SHC 99.2 99.3 83.7 64.9 107.0 107.0 97.1 73.5 113.0 113.0 108.0 81.4
kW 10.80 10.80 11.20 11.60 11.20 11.20 11.40 11.80 11.40 11.40 11.50 11.90
Edb — Entering Dry Bulb
Ewb — Entering Wet Bulb
kW—Compressor Motor Power Input
SHC — Sensible Heat Capacity (1000 Btuh) Gross
TC — Total Capacity (1000 Btuh) Gross
50TFQ004-012
569D072-120, 576C120, 569F120
