PERFORMANCE DATA (cont)
COMBINATION RATINGS (cont)
UNIT 566D240
LEGEND
566D240/524A-C300 WITH HIGH-CAPACITY 4-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
7,500 10,000 12,500
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 244.0 249.0 268.0 291.0 264.0 264.0 279.0 301.0 278.0 278.0 286.0 307.0
SHC 244.0 233.0 194.0 152.0 264.0 264.0 224.0 171.0 278.0 278.0 252.0 189.0
kW 18.90 19.20 19.90 20.80 19.70 19.70 20.30 21.20 20.30 20.30 20.60 21.40
85
TC 239.0 244.0 263.0 284.0 259.0 259.0 273.0 294.0 272.0 272.0 280.0 300.0
SHC 239.0 231.0 192.0 150.0 259.0 259.0 222.0 169.0 272.0 272.0 249.0 187.0
kW 19.70 19.90 20.70 21.60 20.50 20.50 21.10 22.00 21.10 21.10 21.40 22.30
95
TC 230.0 233.0 251.0 272.0 249.0 249.0 260.0 281.0 261.0 261.0 267.0 286.0
SHC 230.0 225.0 187.0 146.0 249.0 249.0 217.0 164.0 261.0 261.0 243.0 182.0
kW 21.30 21.40 22.20 23.20 22.10 22.10 22.70 23.70 22.70 22.70 23.00 23.90
100
TC 226.0 228.0 245.0 265.0 244.0 244.0 254.0 274.0 256.0 256.0 260.0 279.0
SHC 226.0 222.0 184.0 143.0 244.0 244.0 214.0 162.0 256.0 256.0 240.0 180.0
kW 22.00 22.10 23.00 24.00 22.90 22.90 23.50 24.50 23.60 23.60 23.80 24.80
105
TC 221.0 222.0 239.0 259.0 238.0 238.0 247.0 267.0 250.0 250.0 254.0 272.0
SHC 221.0 219.0 182.0 141.0 238.0 238.0 212.0 160.0 250.0 250.0 237.0 177.0
kW 22.80 22.80 23.70 24.80 23.70 23.70 24.20 25.30 24.40 24.40 24.60 25.60
115
TC 212.0 212.0 226.0 245.0 227.0 227.0 235.0 253.0 238.0 238.0 240.0 257.0
SHC 212.0 211.0 177.0 136.0 227.0 227.0 206.0 155.0 238.0 238.0 231.0 172.0
kW 24.30 24.30 25.20 26.40 25.30 25.30 25.80 26.90 26.00 26.00 26.10 27.20
566D240/524A-B300 WITH STANDARD 3-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
7,500 10,000 12,500
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 230.0 236.0 255.0 277.0 249.0 249.0 266.0 287.0 262.0 262.0 272.0 293.0
SHC 230.0 219.0 183.0 144.0 249.0 248.0 209.0 161.0 262.0 262.0 233.0 176.0
kW 18.40 18.60 19.40 20.20 19.10 19.20 19.80 20.60 19.60 19.60 20.10 20.90
85
TC 226.0 231.0 250.0 271.0 244.0 244.0 259.0 281.0 256.0 256.0 266.0 287.0
SHC 226.0 217.0 181.0 142.0 244.0 244.0 207.0 159.0 256.0 256.0 231.0 174.0
kW 19.20 19.40 20.20 21.00 19.90 19.90 20.60 21.50 20.40 20.40 20.80 21.70
95
TC 218.0 221.0 239.0 259.0 235.0 235.0 248.0 268.0 246.0 246.0 254.0 273.0
SHC 218.0 211.0 176.0 138.0 235.0 235.0 203.0 154.0 246.0 246.0 226.0 169.0
kW 20.60 20.80 21.70 22.60 21.50 21.50 22.10 23.10 22.00 22.00 22.40 23.30
100
TC 214.0 217.0 233.0 253.0 230.0 230.0 242.0 261.0 241.0 241.0 248.0 266.0
SHC 214.0 208.0 174.0 136.0 230.0 230.0 200.0 152.0 241.0 241.0 223.0 167.0
kW 21.40 21.50 22.40 23.40 22.20 22.20 22.90 23.80 22.80 22.80 23.20 24.10
105
TC 209.0 212.0 228.0 247.0 225.0 225.0 236.0 255.0 236.0 236.0 242.0 260.0
SHC 209.0 206.0 172.0 133.0 225.0 225.0 198.0 150.0 236.0 236.0 220.0 165.0
kW 22.10 22.20 23.10 24.20 23.00 23.00 23.60 24.60 23.60 23.60 23.90 24.90
115
TC 201.0 202.0 216.0 235.0 215.0 215.0 224.0 242.0 226.0 226.0 229.0 246.0
SHC 201.0 199.0 167.0 129.0 215.0 215.0 193.0 145.0 226.0 226.0 214.0 160.0
kW 23.60 23.70 24.60 25.80 24.60 24.50 25.10 26.20 25.20 25.20 25.40 26.50
Edb — Entering Dry Bulb
Ewb — Entering Wet Bulb
kW—Compressor Motor Power Input
SHC — Sensible Heat Capacity (1000 Btuh) Gross
TC — Total Capacity (1000 Btuh) Gross
50TFQ004-012
566D/E150-240
