45
PERFORMANCE DATA (cont)
COMBINATION RATINGS (cont)
UNIT 566E150
LEGEND
566E150/524A-C120 WITH HIGH-CAPACITY 4-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
3000 4000 5000
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 126.0 135.0 148.0 161.0 140.0 144.0 156.0 170.0 149.0 151.0 162.0 176.0
SHC 126.0 112.0 95.4 78.5 140.0 130.0 109.0 87.0 149.0 146.0 122.0 94.8
kW 9.13 9.18 9.22 9.31 9.19 9.20 9.26 9.37 9.22 9.23 9.30 9.43
85
TC 125.0 133.0 146.0 159.0 138.0 142.0 154.0 168.0 147.0 148.0 159.0 173.0
SHC 125.0 111.0 94.5 77.5 138.0 129.0 108.0 86.0 147.0 144.0 121.0 93.8
kW 9.68 9.72 9.79 9.87 9.74 9.77 9.82 9.92 9.78 9.80 9.85 9.98
95
TC 121.0 129.0 141.0 154.0 134.0 137.0 149.0 162.0 143.0 144.0 154.0 167.0
SHC 121.0 109.0 92.4 75.6 134.0 127.0 106.0 84.0 143.0 141.0 118.0 91.8
kW 10.90 11.00 11.00 11.10 11.00 11.00 11.00 11.10 11.00 11.00 11.10 11.20
100
TC 119.0 127.0 138.0 151.0 132.0 135.0 146.0 159.0 141.0 141.0 151.0 164.0
SHC 119.0 108.0 91.4 74.6 132.0 126.0 105.0 82.9 141.0 140.0 117.0 90.7
kW 11.60 11.60 11.70 11.70 11.60 11.60 11.70 11.80 11.60 11.70 11.70 11.80
105
TC 118.0 124.0 136.0 149.0 130.0 132.0 143.0 156.0 138.0 139.0 148.0 161.0
SHC 118.0 107.0 90.3 73.5 130.0 124.0 104.0 81.9 138.0 138.0 116.0 89.6
kW 12.30 12.30 12.40 12.40 12.30 12.30 12.40 12.50 12.30 12.40 12.40 12.50
115
TC 114.0 120.0 131.0 143.0 126.0 127.0 137.0 150.0 134.0 134.0 142.0 154.0
SHC 114.0 104.0 88.0 71.4 126.0 122.0 101.0 79.6 134.0 134.0 114.0 87.4
kW 13.70 13.80 13.80 13.90 13.80 13.80 13.80 13.90 13.80 13.80 13.90 14.00
566E150/524A-B120 WITH STANDARD 3-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
3000 4000 5000
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 119.0 128.0 140.0 153.0 131.0 136.0 148.0 161.0 140.0 142.0 153.0 166.0
SHC 119.0 106.0 90.4 74.3 131.0 122.0 103.0 82.0 140.0 136.0 114.0 89.0
kW 9.09 9.15 9.18 9.23 9.15 9.16 9.21 9.30 9.19 9.19 9.25 9.33
85
TC 118.0 126.0 138.0 151.0 130.0 134.0 146.0 159.0 138.0 140.0 151.0 164.0
SHC 118.0 105.0 89.5 73.4 130.0 121.0 102.0 81.2 138.0 135.0 113.0 88.1
kW 9.66 9.72 9.75 9.81 9.72 9.72 9.77 9.87 9.75 9.75 9.80 9.89
95
TC 115.0 122.0 134.0 146.0 126.0 130.0 141.0 154.0 134.0 136.0 146.0 158.0
SHC 115.0 103.0 87.7 71.7 126.0 119.0 99.9 79.3 134.0 132.0 111.0 86.3
kW 10.90 10.90 11.00 11.00 10.90 10.90 11.00 11.10 11.00 11.00 11.00 11.10
100
TC 113.0 120.0 131.0 144.0 124.0 128.0 139.0 151.0 132.0 133.0 143.0 156.0
SHC 113.0 102.0 86.7 70.8 124.0 118.0 98.9 78.4 132.0 131.0 110.0 85.3
kW 11.60 11.60 11.60 11.70 11.60 11.60 11.60 11.70 11.60 11.60 11.70 11.80
105
TC 111.0 118.0 129.0 141.0 122.0 125.0 136.0 148.0 130.0 131.0 140.0 153.0
SHC 111.0 101.0 85.7 69.8 122.0 117.0 97.9 77.5 130.0 129.0 109.0 84.3
kW 12.20 12.30 12.30 12.40 12.30 12.30 12.30 12.40 12.30 12.30 12.40 12.40
115
TC 108.0 114.0 124.0 136.0 118.0 121.0 131.0 143.0 126.0 126.0 135.0 147.0
SHC 108.0 99.0 83.7 67.8 118.0 114.0 95.8 75.4 126.0 126.0 107.0 82.3
kW 13.70 13.70 13.80 13.90 13.70 13.80 13.80 13.90 13.80 13.80 13.80 13.90
Edb — Entering Dry Bulb
Ewb — Entering Wet Bulb
kW—Compressor Motor Power Input
SHC — Sensible Heat Capacity (1000 Btuh) Gross
TC — Total Capacity (1000 Btuh) Gross
50TFQ004-012
566D/E150-240
