46
PERFORMANCE DATA (cont)
COMBINATION RATINGS (cont)
UNIT 566E150 (cont)
LEGEND
566E150/524A-C150 WITH HIGH-CAPACITY 4-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
3750 5000 6250
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 139.0 145.0 158.0 172.0 152.0 154.0 165.0 180.0 161.0 161.0 170.0 185.0
SHC 139.0 127.0 107.0 86.2 152.0 148.0 123.0 96.1 161.0 161.0 138.0 105.0
kW 9.18 9.21 9.27 9.38 9.25 9.24 9.33 9.48 9.29 9.31 9.37 9.54
85
TC 137.0 143.0 155.0 169.0 150.0 151.0 163.0 177.0 159.0 159.0 168.0 182.0
SHC 137.0 126.0 106.0 85.3 150.0 146.0 122.0 95.1 159.0 159.0 137.0 104.0
kW 9.74 9.76 9.84 9.95 9.80 9.82 9.90 10.00 9.86 9.87 9.93 10.10
95
TC 133.0 138.0 150.0 164.0 146.0 147.0 157.0 171.0 154.0 154.0 162.0 175.0
SHC 133.0 124.0 104.0 83.3 146.0 144.0 120.0 93.1 154.0 154.0 134.0 102.0
kW 11.00 11.00 11.10 11.20 11.00 11.00 11.10 11.20 11.10 11.10 11.10 11.30
100
TC 131.0 136.0 148.0 161.0 143.0 144.0 154.0 168.0 152.0 152.0 159.0 172.0
SHC 131.0 123.0 103.0 82.2 143.0 142.0 119.0 92.1 152.0 152.0 133.0 101.0
kW 11.60 11.60 11.70 11.80 11.70 11.70 11.80 11.90 11.70 11.70 11.80 11.90
105
TC 129.0 133.0 145.0 158.0 141.0 142.0 152.0 165.0 149.0 149.0 156.0 169.0
SHC 129.0 121.0 102.0 81.1 141.0 140.0 118.0 90.9 149.0 149.0 132.0 100.0
kW 12.30 12.30 12.40 12.50 12.40 12.40 12.50 12.60 12.40 12.40 12.50 12.60
115
TC 125.0 128.0 139.0 152.0 136.0 136.0 145.0 158.0 144.0 144.0 150.0 162.0
SHC 125.0 119.0 99.4 78.9 136.0 136.0 115.0 88.7 144.0 144.0 129.0 97.9
kW 13.80 13.80 13.90 14.00 13.80 13.90 13.90 14.00 13.90 13.90 13.90 14.10
566E150/524A-B150 WITH STANDARD 3-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
3750 5000 6250
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 130.0 137.0 150.0 163.0 143.0 145.0 157.0 171.0 151.0 151.0 162.0 176.0
SHC 130.0 120.0 101.0 81.6 143.0 138.0 115.0 90.5 151.0 151.0 128.0 98.5
kW 9.14 9.18 9.22 9.32 9.20 9.20 9.27 9.38 9.24 9.23 9.30 9.43
85
TC 129.0 135.0 147.0 161.0 141.0 143.0 154.0 168.0 149.0 149.0 159.0 173.0
SHC 129.0 119.0 100.0 80.7 141.0 137.0 114.0 89.5 149.0 149.0 127.0 97.5
kW 9.70 9.73 9.78 9.88 9.76 9.76 9.82 9.93 9.79 9.79 9.85 9.98
95
TC 125.0 131.0 143.0 156.0 137.0 138.0 149.0 162.0 145.0 145.0 154.0 167.0
SHC 125.0 117.0 98.0 78.7 137.0 134.0 112.0 87.5 145.0 145.0 125.0 95.6
kW 10.90 11.00 11.00 11.10 11.00 11.00 11.00 11.10 11.00 11.00 11.10 11.20
100
TC 123.0 128.0 140.0 153.0 135.0 136.0 146.0 160.0 143.0 143.0 151.0 164.0
SHC 123.0 115.0 97.0 77.7 135.0 132.0 111.0 86.5 143.0 143.0 124.0 94.5
kW 11.60 11.60 11.70 11.70 11.60 11.70 11.70 11.80 11.70 11.70 11.70 11.80
105
TC 122.0 126.0 137.0 150.0 132.0 133.0 144.0 157.0 140.0 140.0 148.0 161.0
SHC 122.0 114.0 95.9 76.7 132.0 131.0 110.0 85.4 140.0 140.0 123.0 93.5
kW 12.30 12.30 12.30 12.40 12.30 12.30 12.40 12.50 12.30 12.40 12.40 12.50
115
TC 118.0 121.0 132.0 144.0 128.0 128.0 138.0 150.0 135.0 135.0 142.0 154.0
SHC 118.0 112.0 93.6 74.5 128.0 128.0 108.0 83.3 135.0 135.0 120.0 91.3
kW 13.80 13.80 13.80 13.90 13.80 13.80 13.90 14.00 13.80 13.80 13.90 14.00
Edb — Entering Dry Bulb
Ewb — Entering Wet Bulb
kW—Compressor Motor Power Input
SHC — Sensible Heat Capacity (1000 Btuh) Gross
TC — Total Capacity (1000 Btuh) Gross
50TFQ004-012
566D/E150-240
