Bryant 566D User Manual

47
PERFORMANCE DATA (cont)
COMBINATION RATINGS (cont)
UNIT 566E150 (cont)
LEGEND
566E150/524A-C180 WITH HIGH-CAPACITY 4-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
4500 6000 7500
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 152.0 156.0 169.0 183.0 166.0 166.0 176.0 190.0 175.0 175.0 181.0 195.0
SHC 152.0 145.0 121.0 95.4 166.0 166.0 140.0 107.0 175.0 175.0 157.0 119.0
kW 9.24 9.26 9.35 9.53 9.33 9.33 9.43 9.63 9.42 9.43 9.49 9.69
85
TC 150.0 154.0 166.0 181.0 164.0 164.0 173.0 187.0 173.0 173.0 178.0 191.0
SHC 150.0 144.0 120.0 94.4 164.0 164.0 139.0 106.0 173.0 173.0 156.0 118.0
kW 9.80 9.82 9.92 10.10 9.89 9.89 9.99 10.20 9.98 9.99 10.00 10.20
95
TC 146.0 148.0 161.0 175.0 159.0 159.0 167.0 181.0 167.0 167.0 172.0 185.0
SHC 146.0 141.0 117.0 92.2 159.0 159.0 136.0 104.0 167.0 167.0 154.0 115.0
kW 11.00 11.10 11.10 11.30 11.10 11.10 11.20 11.40 11.20 11.20 11.20 11.40
100
TC 144.0 146.0 158.0 171.0 156.0 156.0 164.0 178.0 165.0 165.0 169.0 181.0
SHC 144.0 140.0 116.0 91.1 156.0 156.0 135.0 103.0 165.0 165.0 152.0 114.0
kW 11.70 11.70 11.80 11.90 11.80 11.80 11.90 12.00 11.80 11.90 11.90 12.10
105
TC 141.0 143.0 155.0 168.0 154.0 154.0 161.0 174.0 162.0 162.0 165.0 178.0
SHC 141.0 138.0 115.0 90.0 154.0 154.0 134.0 102.0 162.0 162.0 151.0 113.0
kW 12.40 12.40 12.50 12.60 12.50 12.50 12.50 12.70 12.50 12.50 12.60 12.80
115
TC 137.0 138.0 148.0 162.0 148.0 148.0 154.0 167.0 156.0 156.0 159.0 170.0
SHC 137.0 135.0 112.0 87.6 148.0 148.0 131.0 99.5 156.0 156.0 148.0 111.0
kW 13.90 13.90 13.90 14.10 13.90 14.00 14.00 14.20 14.00 14.00 14.00 14.20
566E150/524A-B180 WITH STANDARD 3-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
4500 6000 7500
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 143.0 147.0 160.0 174.0 155.0 156.0 166.0 180.0 164.0 164.0 171.0 185.0
SHC 143.0 136.0 113.0 89.9 155.0 155.0 130.0 100.0 164.0 164.0 146.0 110.0
kW 9.19 9.22 9.28 9.42 9.27 9.26 9.34 9.49 9.31 9.33 9.37 9.54
85
TC 141.0 145.0 157.0 171.0 153.0 153.0 164.0 178.0 162.0 162.0 168.0 182.0
SHC 141.0 134.0 112.0 89.0 153.0 153.0 129.0 99.5 162.0 162.0 144.0 109.0
kW 9.75 9.77 9.85 9.98 9.82 9.82 9.90 10.00 9.87 9.89 9.93 10.10
95
TC 137.0 140.0 152.0 165.0 149.0 149.0 158.0 172.0 157.0 157.0 162.0 175.0
SHC 137.0 132.0 110.0 86.9 149.0 149.0 127.0 97.4 157.0 157.0 142.0 107.0
kW 11.00 11.00 11.10 11.20 11.00 11.00 11.10 11.20 11.10 11.10 11.10 11.30
100
TC 135.0 138.0 149.0 162.0 146.0 146.0 155.0 168.0 154.0 154.0 159.0 172.0
SHC 135.0 131.0 109.0 85.8 146.0 146.0 126.0 96.3 154.0 154.0 141.0 106.0
kW 11.60 11.60 11.70 11.80 11.70 11.70 11.80 11.90 11.70 11.80 11.80 11.90
105
TC 133.0 135.0 146.0 159.0 144.0 144.0 152.0 165.0 152.0 152.0 156.0 169.0
SHC 133.0 129.0 108.0 84.7 144.0 144.0 125.0 95.2 152.0 152.0 139.0 105.0
kW 12.30 12.30 12.40 12.50 12.40 12.40 12.50 12.60 12.40 12.50 12.50 12.60
115
TC 129.0 130.0 140.0 153.0 139.0 139.0 146.0 158.0 146.0 146.0 150.0 162.0
SHC 129.0 126.0 106.0 82.5 139.0 139.0 122.0 92.9 146.0 146.0 137.0 103.0
kW 13.80 13.80 13.90 14.00 13.90 13.90 13.90 14.10 13.90 13.90 13.90 14.10
Edb — Entering Dry Bulb
Ewb — Entering Wet Bulb
kW—Compressor Motor Power Input
SHC — Sensible Heat Capacity (1000 Btuh) Gross
TC — Total Capacity (1000 Btuh) Gross
50TFQ004-012
566D/E150-240
