PERFORMANCE DATA (cont)
COMBINATION RATINGS (cont)
UNIT 566E180
LEGEND
566E180/524A-C150 WITH HIGH-CAPACITY 4-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
3750 5000 6250
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 163.0 175.0 190.0 206.0 179.0 186.0 201.0 217.0 191.0 194.0 208.0 224.0
SHC 161.0 142.0 121.0 99.8 179.0 164.0 138.0 110.0 191.0 184.0 153.0 119.0
kW 12.60 12.80 13.20 13.60 12.90 13.10 13.40 13.80 13.20 13.30 13.60 14.00
85
TC 160.0 172.0 187.0 203.0 176.0 183.0 198.0 214.0 188.0 190.0 204.0 220.0
SHC 159.0 141.0 120.0 98.5 176.0 163.0 136.0 109.0 188.0 182.0 151.0 118.0
kW 13.10 13.40 13.80 14.20 13.50 13.70 14.00 14.40 13.80 13.80 14.20 14.60
95
TC 155.0 166.0 180.0 196.0 170.0 176.0 190.0 206.0 181.0 183.0 196.0 212.0
SHC 155.0 138.0 117.0 95.6 170.0 159.0 133.0 106.0 181.0 178.0 148.0 115.0
kW 14.30 14.60 15.00 15.40 14.70 14.80 15.20 15.70 15.00 15.00 15.40 15.80
100
TC 152.0 163.0 177.0 192.0 167.0 172.0 186.0 201.0 178.0 180.0 192.0 208.0
SHC 152.0 136.0 115.0 94.0 167.0 158.0 131.0 104.0 178.0 176.0 146.0 113.0
kW 14.90 15.20 15.60 16.00 15.30 15.50 15.80 16.30 15.60 15.60 16.00 16.50
105
TC 150.0 159.0 173.0 188.0 164.0 168.0 182.0 197.0 175.0 176.0 188.0 203.0
SHC 150.0 134.0 114.0 92.4 164.0 156.0 130.0 102.0 175.0 173.0 145.0 112.0
kW 15.60 15.80 16.20 16.60 16.00 16.10 16.50 16.90 16.30 16.30 16.60 17.10
115
TC 144.0 152.0 165.0 179.0 158.0 161.0 173.0 188.0 168.0 168.0 178.0 193.0
SHC 144.0 131.0 110.0 89.1 158.0 152.0 126.0 99.0 168.0 167.0 141.0 108.0
kW 16.90 17.10 17.50 18.00 17.30 17.40 17.80 18.20 17.60 17.60 17.90 18.40
566E180/524A-B150 WITH STANDARD 3-ROW COIL
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air — Cfm
3750 5000 6250
Evaporator Air — Ewb (F)
57 62 67 72 57 62 67 72 57 62 67 72
80
TC 154.0 166.0 181.0 196.0 168.0 176.0 191.0 206.0 179.0 183.0 197.0 213.0
SHC 152.0 134.0 115.0 94.7 168.0 154.0 129.0 104.0 179.0 171.0 143.0 112.0
kW 12.40 12.60 13.00 13.30 12.70 12.90 13.20 13.60 12.90 13.00 13.40 13.70
85
TC 152.0 163.0 178.0 193.0 166.0 173.0 188.0 203.0 176.0 180.0 194.0 210.0
SHC 150.0 133.0 113.0 93.4 166.0 153.0 128.0 102.0 176.0 169.0 141.0 111.0
kW 12.90 13.20 13.50 13.90 13.20 13.40 13.80 14.20 13.50 13.60 13.90 14.30
95
TC 147.0 157.0 171.0 186.0 160.0 167.0 180.0 196.0 171.0 173.0 187.0 202.0
SHC 146.0 130.0 111.0 90.6 160.0 149.0 125.0 99.7 171.0 166.0 138.0 108.0
kW 14.10 14.40 14.70 15.10 14.40 14.60 15.00 15.40 14.70 14.80 15.10 15.50
100
TC 144.0 154.0 168.0 182.0 158.0 163.0 177.0 191.0 167.0 170.0 182.0 197.0
SHC 144.0 128.0 109.0 89.1 158.0 148.0 123.0 98.1 167.0 163.0 137.0 106.0
kW 14.80 15.00 15.30 15.70 15.10 15.20 15.60 16.00 15.30 15.40 15.70 16.20
105
TC 141.0 151.0 164.0 179.0 155.0 160.0 173.0 187.0 164.0 166.0 178.0 193.0
SHC 141.0 127.0 107.0 87.6 155.0 146.0 122.0 96.5 164.0 161.0 135.0 105.0
kW 15.40 15.60 16.00 16.40 15.70 15.80 16.20 16.60 16.00 16.00 16.40 16.80
115
TC 136.0 144.0 157.0 170.0 149.0 152.0 165.0 178.0 158.0 159.0 170.0 183.0
SHC 136.0 124.0 104.0 84.4 149.0 142.0 118.0 93.3 158.0 156.0 132.0 101.0
kW 16.80 16.90 17.30 17.70 17.10 17.20 17.50 17.90 17.30 17.30 17.70 18.10
Edb — Entering Dry Bulb
Ewb — Entering Wet Bulb
kW—Compressor Motor Power Input
SHC — Sensible Heat Capacity (1000 Btuh) Gross
TC — Total Capacity (1000 Btuh) Gross
50TFQ004-012
566D/E150-240
