Bryant 925TA - Venting; Special Venting Requirements for Installations in Canada

37
A12226
Fig. 32 -- Installing J--Box (When Used)
COPPER
WIRE ONLY
ELECTRIC
DISCONNECT
SWITCH
ALUMINUM
WIRE
GROUND
NEUTRAL
LINE VOLTAGE
A11146
Fig. 33 -- Field--Supplied Electrical Box on Furnace Casing
24 V
Coil
To Humidifier Leads
To Com/24V Screw Terminal
on Thermostat Strip
To HUM Terminal On
Furnace Control Board
To Humidifier Leads
A11157
Fig. 34 -- Field--supplied Isolation Relay for Humidifiers with Internal Power Supply
925TA
