Bryant BW9 - Page 49

KEY NO. ITEM NUMBER DESCRIPTION QUANTITY
1 14631023 Burner Gasket 1
2a 14631006 BW9-100 Burner 1
2b 14631007 BW9-75 Burner 1
2c 14631008 BW9-50 Burner 1
3 14631025 Mixer Gasket 5
4 14695810 1/4-in. -20 Hex Nut w/ Serrated Washer Head 1
5 12101008 Mixer Casting Machined 1
6 14631311 2-in. X 1-1/2-in. Flexible Coupling 1
7a 42531100 BW9-100 Air Baffle 1
7b 42531101 BW9-75 Air Baffle 1
7c 42531102 BW9-50 Air Baffle 1
8 42531103 Air Inlet 1
9 14631015 2-in. Fernco Coupling 1
10 14695809 10-32-in. X 3/8-in. Machine Screw 2
11 4380013 BW9–Ignitor 1
12 14631024 Hot Surface Igniter Gasket 1
13 14631309 Mixer Bushing 1
14 14607301 1/2-in. X 3-in. Std Black Nipple 1
15 14693805 1/8-in. NPT Steel Plug — 3/16-in. Hex Socket 3
16 14631307 Honeywell Gas Valve VR8205 1
17 14631308 5/16-24 X 1/4 Hose ID Brass Barb Fitting 1
18 14631104 62064 1/4-in. ID Tube Tee 1
19 14631313 1/4-in. ID Tube 4-way Connector 1
20 14631143 1/4-in. ID Tube 4-way Connector3/8-in. Hose Clamp HC-6ST 10
21 14631151 PC250-12 Vinyl Cap 2
22 14631033 59006 1/4-in. ID X 3/8-in. OD Vinyl Tubing AS REQUIRED
23 14631314 1/4-in. ID X 3/8-in. OD Vinyl Tubing (Red) AS REQUIRED
24 14629003 1/4-in. ID Silicone Tubing AS REQUIRED
25a 14631312 PPS10111-2680 Air Pressure Switch (BW9-100) 1
25b 14631010 PPS10111-2681 Air Pressure Switch (BW9-75) 1
25c 14631044 PPS10111-2682 Air Pressure Switch (BW9-50) 1
26 14631103 62043 1/2-in. NPT X 1/2-in. ID Tube Elbow 1
27a 14631310 Gas Orifice — Natural, 100N (0.0860) 1
27b 14631029 Gas Orifice — Natural, 75N (0.0760) 1
27c 14631030 Gas Orifice — Natural, 50N (0.615) 1
27d 14631032 Gas Orifice — Propane, 100P (0.0670) 1
27e 14631036 Gas Orifice — Propane, 75P (0.0605) 1
27f 14631037
Gas Orifice — Propane, 75P (0.0605)Gas Orifice — Propane,
50P (0.0492)
1
28 14691002 Tie Nylon 1
