506 01 2303 01 35
Specifications are subject to change without notice.
Fans
Service
Valves
C11047
Fig. 30 -- CHS091 Exterior
LOC
HPS
High Flow
Access Ports
Outdoor Coil
Defrost
Thermostat
(DFT)
C150033
Fig. 31 -- CHS091 Interior
