2SP H/C (2 SPEED HEAT/COOL) FAN OPERATION
FAN TYPE = 2SP H/C is not used on 581K***F/K units.
3 SPEED FAN OPERATION (SINGLE PHASE UNITS ONLY)
The W7220 controller does not actually control the fan speed
or the heat output of the unit, and only uses this information to
help determine the damper position. On single phase units, the
unit control board (UCB) will reduce the fan speed during
heating when the configured fan speed is set outside the opti-
mized heating speed window. If the job site application forces
this reduction in fan speed during heat, the economizer FAN
TYPE must be set to keep the appropriate outside air intake.
On single phase 581K***F/K units, if reduced the heating fan
speed is lower than the high cooling speed and higher than the
low cooling speed, hence the medium speed name. The econo-
mizer FAN TYPE needs to be set to 3SPEED (3 speed). This
indicates that the heating fan speed is between the Low cool/
vent fan speed and the High cool speed. Refer to Table 14 for
economizer operation.
*With stage 3 delay (STG3 DLY) in Advanced setup, COOL Y2-OUT will be turned ON after the delay time specified.
N/A = Not applicable
Table 14 — Economizer Operation - FAN TYPE = 3SPEED
INPUTS OUTPUTS
DEMAND
CONTROLLED
VENTILATION
(DCV)
OUTSIDE AIR
GOOD TO
ECONOMIZE
W
(HEAT ON)
COOL
Y1-IN
COOL
Y2-IN
COOL
Y1-OUT
COOL
Y2-OUT
FAN SPEED
(reference
only)
DAMPER POSITION
OCCUPIED UNOCCUPIED
NONE
NO
ON N/A N/A OFF OFF MEDIUM MIN POS M Closed
OFF OFF OFF OFF OFF LOW MIN POS L Closed
OFF ON OFF ON OFF LOW MIN POS L Closed
OFF ON ON ON ON HIGH MIN POS H Closed
YES
ON N/A N/A OFF OFF MEDIUM MIN POS M Closed
OFF OFF OFF OFF OFF LOW MIN POS L Closed
OFF ON OFF OFF OFF LOW
MIN POS L to
Full Open
Closed to
Full Open
OFF ON ON ON OFF* HIGH
MIN POS H to
Full Open
Closed to
Full Open
Below CO
2
Set
NO
ON N/A N/A OFF OFF MEDIUM VENTMIN M Closed
OFF OFF OFF OFF OFF LOW VENTMIN L Closed
OFF ON OFF ON OFF LOW VENTMIN L Closed
OFF ON ON ON ON HIGH VENTMIN H Closed
YES
ON N/A N/A OFF OFF MEDIUM VENTMIN M Closed
OFF OFF OFF OFF OFF LOW VENTMIN L Closed
OFF ON OFF OFF OFF LOW
VENTMIN L to
Full Open
Closed to
Full Open
OFF ON ON ON OFF* HIGH
VENTMIN H to
Full Open
Closed to
Full Open
Above CO
2
Set
NO
ON N/A N/A OFF OFF MEDIUM
VENTMIN M to
VENTMAX M
Closed
OFF OFF OFF OFF OFF LOW
VENTMIN L to
VENTMAX L
Closed
OFF ON OFF ON OFF LOW
VENTMIN L to
VENTMAX L
Closed
OFF ON ON ON ON HIGH
VENTMIN H to
VENTMAX H
Closed
YES
ON N/A N/A OFF OFF MEDIUM
VENTMIN M to
VENTMAX M
Closed
OFF OFF OFF OFF OFF LOW
VENTMIN L to
VENTMAX L
Closed
OFF ON OFF OFF OFF* LOW
VENTMIN L to
Full Open
Closed to
Full Open
OFF ON ON ON OFF*
HIGH
VE
NTMIN H to
Full Open
Closed to
Full Open
To Next Page
