Bside ADM01 User Manual

1. Introduction
This manual is used to ADM01 and ADM02 Digital Muti Meter only.
This Meter is a handheld and battery operated Digital
MultiMeter(DMM) with multi function. This Meter is designed to meet
IEC61010-1 & CAT II 600V over voltage category and double insulation.
The meter with holster that is giving the main body, though
downsized, high resistance against the shock of a drop.
This operating instruction covers information on safety and caution.
Please read relevant information carefully and observe all the
warnings and note strictly.
The DMM as general measurement tool and widely used in the school,
laboratory, factory and other social field.
2. Safety note
Warning
To avoid possible electric shock or personal injury and to avoid
possible damage to the meter or to the equipment under test, adhere
to the following rule:
 Do not apply more than the rated voltage, of marked
on the meter, between the input terminal and
grounding terminal..
 Do not apply voltage between COM and OHM terminal,
in the resistance measuring state.

Do not measure current with test lead inserted into
voltage or OHM terminal.

Do not expose the instrument to the direct sun light,
extreme temperature and humidity or dew full.
 Inspect the test lead for damaged insulation or
exposed metal.

Before measuring current, check the Meter’s fuses and
turn off power to the circuit before connecting the
meter to the circuit.

Disconnect circuit power and discharge all high
1
