Bside ADM01 - Controls and Indicators Explanation; Meter Illustration

voltage capacitors before testing continuity, diode,
resistance, capacitance or current.
Note international Electrical Symbol.
Dangerous
Voltage
Ground
AC Alternating
current
Warning
see explain in manual
DC (Direct
Current)
Double insulation
AC or DC
Fuse
Measurement category(over voltage category):
This instrument is meet the safety condition of CAT II. The
equipment is used for measurement in building facilities.
Examples are measurements on distribution boards, circuit
breaker and industrial equipment located in fixed facilities, as
a fixed motor.
3. Explanation of controls and indicators
3-1. Meter illustration
2
