Bside ADM01 User Manual

●
Power Supply: 9V Battery(6F22 or 1604A Type) x 1pc.
● Safety Class: IEC 61010-1, CAT II 600V.
●
Dimension(L x W x H) & Weight:140 x 67 x 30mm, Approx. 112g
4.1.1 Accessary:
1. User’s Manual ---------------------------- 1pc
2. Test lead ---------------------------- 1set
3. 9V Battery --------------------------- 1pc
4. K-type temperature probe---- 1pc(For ADM02)
4-2. Electrical Specification ( at 23±5℃; <75% RH)
4.2.1 DC Voltage
Range
Resolution
Accuracy
200mV
0.1mV
±（0.5% rdg + 2dgt）
2V
0.001V
20V
0.01V
200V
0.1V
600V
1V
±
（
0.8% rdg + 2dgt
）
* Over load protection: SG(Spark Gap) used to protect that the
voltage overred 1500V
4.2.2 AC Voltage
Range
Resolution
Accuracy
2V (40Hz-400Hz)
0.001V
±（0.9% rdg + 3dgt）
20V (40Hz-400Hz)
0.01V
200V (40Hz-400Hz)
0.1V
600V (40Hz-200Hz)
1V
±
（
1.2%
）
rdg + 3dgt
* SG(Spark Gap) used to protect High voltage that is
over 1500V.
7
