1. LCD display 2. “MAX” push button 3. “BACK LIGHT” push
button 4. ‘HOLD” push button 5. “FUNC” Push button
6. Rotary Switch (Knob) 7. “V/Ω/HZ/uA/mA/Temp”Input terminal
[‘Hz’ is for ADM01 and ‘Temp’ is for ADM02]
8. “COM” input terminal 9. “10A” input terminal
3-2. Functional push button
“FUNC” key is the function select key that acts
with trigger. Use the key as switch of DC/AC
current, Diode/Continuity and
℃
/
℉
.
Press “HOLD” to enter and exit the hold mode
in any mode. That act with trigger.
This key is act with trigger. Press this key once,
the maximum value is holding (Will displays
‘MAX’ symbol in the LCD).
After pressing the key, A/D will keep working,
and the display value are always up dated and
kept the maximum value.
NOTE: The actual gained value is not the peak
value.
This key is used control Backlight. This key is act
with trigger. When press and hold the key over
2 sec, will enable Backlight.
Press the key again , the backlight will disable.
