Bticino Sfera Installer Manual

Sfera Proximity Reader
Installer manual
7
2.3 Back view
1 - Connection to the door lock (CP-P1) and tamper
(CP-P2 – future application) pushbutton.
2 - Local relay contacts.
3 - Connection to the BUS.
4 - Connector for the connection to subsequent modules.
5 - Connector for the connection to previous modules.
6 - Configurator sockets.
3 2 1
5
4
6
