Installation and Connections
SM-DIN/MULTILOOP.. - 1.3 -
Technical Characteristics
Power supply voltage
12-15VAC - 24 VDC
Maximum absorption
200 mA Max
Protection fuse (Board protection)
3 A
Protection fuse (sensors supply)
3 A
STOP output (normally open contacts)
0.3 A 125 VAC
1 A 30 VDC
Inputs
0 – 24 VDC
VIL Max 1.2 VDC
VIH Min 5 VDC
Operating temperature range
+10° / +60° C
Storage temperature
-25° / +85° C
Overall dimensions
138.5x124x35 mm
