btsr SM-DIN/MULTILOOP/ETH - Device Update

Installation and Connections
SM-DIN/MULTILOOP.. - 2.15 -
DEVICE UPDATE
(Debug/Service option)
Enter the BOARD SETUP menu.
Select DEVICE UPDATE
to choose which device from TS55 to ACTD need to update
to confirm the device from TS55 and ACTD to update
SET POINT
Enter the WRK PARAMETERS menu.
Select SET POINT (tension applied to the elastic yarn exiting from
the system).
/
To change the parameter value [12 cN … 1000 cN]
To go to next page
3 sec to confirm and go back to WRK PARAMETERS menu
WRK PARAMETERS
→
SET POINT
BOARD SETUP
→
DEVICE UPDATE
