Installation and Connections
SM-DIN/MULTILOOP.. - 2.28 -
To zoom the graph.
3 sec to go to main menu
BOARD INFORMATION
Enter the BOARD SETUP menu.
Select BOARD INFO.
FW = firmware version loaded on the device
To go to next page
MAC ADDRESS = unique number associated with the Ethernet interface of the
Board
To go to next page
ANYBUS = version of internal PLC communication board
3 sec to go back to BOARD SETUP menu
BOARD SETUP
→
BOARD INFO
