INTRODUCTION
This operating manual contains the necessary instruction for a correct installation and configuration of the SM-
DIN/MULTILOOP/.. Boards available either in ETH (for standard Ethernet network connection) or PFN (for Profinet
®
network connection) version.
The SM-DIN/MULTILOOP/.. Board is typically used on BTSR/Matrix Cube/Matrix Cube 2/ Matrix Cube 3 systems
equipped with TMS devices that allow you to monitor not only the elastic yarn tension on both the application point
and on the creel, but also the yarn running speed.
REFERENCE DOCUMENTATION
The SM-DIN/MULTILOOP/.. Board is a key component of the following BTSR systems:
▪ Matrix Cube
▪ Matrix Cube 2
▪ Matrix Cube 3
For more information about the technical characteristics and the operating mode of such systems, please refer to the
relevant operating manuals:
MATRIX CUBE 1-2-3 (Rev. 6.0 – February 2017, Rev. 3.0 – February 2017, Rev. 1.0 – June 2017)
MATRIX TOUCH DIAPER (Rev. 3.1 – May 2024)
SYMBOLS USED AND NOTES
This background is used to point-out notes, warnings and other important information.
Inside the manual, the SM-DIN/MULTILOOP/ETH Board and the SM-DIN/MULTILOOP/PFN
Board will be generally indicated as SM-DIN/MULTILOOP/..
3 sec = Keep this button pressed for 3 seconds
For detailed information related to functions availability and correspondent firmware version, please refer to dedicate
section “2.7 FUNCTIONS AND FIRMWARE VERSION DETAILS” at the end of the manual.
