btsr SM-DIN/MULTILOOP/ETH - Speed Control

Installation and Connections
SM-DIN/MULTILOOP.. - 2.16 -
EXCLUSION TENSION
Enter the WRK PARAMETERS menu.
Select EXC TENSION. The exclusion tension is the tension kept by
the sensors with machine stationary.
/
To change the parameter value [12 cN … 1000 cN]
To go to next page
3 sec to confirm and go back to WRK PARAMETERS menu
SPEED CONTROL
(Only if LOOP MODE = MULTILOOP)
Enter the WRK PARAMETERS menu.
Select SPEED CONTROL.
/
To change the parameter value
OFF = To deactivate the speed control
ON = To activate the speed control
3 sec to confirm and go back to WRK PARAMETERS menu
WRK PARAMETERS
→
EXC TENSION
WRK PARAMETERS
→
SPEED CONTROL
