Installation and Connections
SM-DIN/MULTILOOP.. - 2.17 -
OUTPUT SPEED SETTING
(Only if LOOP MODE = MULTILOOP)
Enter the WRK PARAMETERS menu.
Select SPEED SETPOINT.
/
To change the parameter value [50 m/M … 999 m/M] or
AUTO = The system set as setpoint the average output speed
BUS = The system set as setpoint the value received from PLC
through software integration logic
3 sec to confirm and go back to WRK PARAMETERS menu
SPEED START
(Only if LOOP MODE = MULTILOOP)
Enter the WRK PARAMETERS menu.
Select SPEED START: Speed control activation delay after the
tension has been kept constant for the set time.
/
To change the parameter value [5 s … 100 s]
3 sec to confirm and go back to WRK PARAMETERS menu
WRK PARAMETERS
→
SPEED START
WRK PARAMETERS
→
SPEED SETPOINT
