Installation and Connections
SM-DIN/MULTILOOP.. - 1.5 -
xxx= ETH (Ethernet/IP)
y=M (Single phase)
xxx= PFN (Profinet)
y=T (Three phase)
Figure 4 - Electrical box
110/220 or 380/480 Vac
power cable
Start / Stop /
Alarm, etc signal
cable
Connection of
DIAPERFEEDER devices
TMS/TS55
connection
MATRIX TOUCH DIAPER
connection
