Buddipole PowerPlus - Specifications

Technical Specification
POWERplus User Guide 1.1.0 15 350-00104-4
SPECIFICATIONS
Battery Type
Lithium Iron Phosphate (LiFePO4)
or Lead Acid (PbSO4).
Absolute Maximum DC Input Voltage
1
20 V DC
Minimum DC Input Voltage
11 VDC
Minimum Battery Input Voltage
10 V DC
Maximum Battery Input Voltage
16 V DC
Maximum Load Current
35 A (total 40A max)
Maximum Charge Current
6 A
Number of DC output ports
4
Number of USB outputs
2
Maximum USB output current
1.5A maximum (each port)
DC power connectors
Anderson Powerpole® 45A
Reverse Polarity Protection
DC and Battery inputs
Over voltage disconnect range
14 – 16 V (user adjustable)
Low voltage disconnect range (battery)
10 – 13 V (user adjustable)
Audible alarm
User settable enable, disable
Overall Size
7.5” (W) x 3.2” (D) x 1.3” (H)
190 (W) x 82 (D) x 33 (H) mm
Weight
11.3oz (320.3 g).
Operating Temperature Range
0 – 40 degrees Celsius
1
The maximum dc input and battery voltage is the maximum that the POWERplus will accept. The
voltage will not be applied to the radio unless it is below the High V limit set in the user settings.
