Installation 1
Wall-mounted condensing gas boiler Buderus 800 - Subject to modifications resulting from technical improvements!
7
800 - 24T25H / 800 - 29T25H
(7 ")
1
2
190
685 mm (27")
420 mm
1
2
(16 ")
75
(3")
40 (1 ")
1
2
30 (1 ")
1
5
431 mm (17")
75
(3")
55
1
7
(2 ")
335 mm
(13 ")
1
7
115 mm
(4 ")
1
2
900 mm (35 ")
1
2
75
(3")
300
(11 ")
5
4
152 mm
(6")
CH flow
CH return
CWDO
GAS
DHW warm
DHW cold
DHW warm
out
= hot water outlet 15 mm dia.
DHW cold in = cold water inlet 15 mm dia.
GAS = gas connection R½ (800 - 24T25H/29T25H)
CH return = boiler return line 28 mm dia.
CH flow = boiler flow line 28 mm dia.
CWDO = condensate water drain 32 mm dia.
Minimum side clearance required for all boilers is 100 mm (4")
