5 Information on setting the programming unit
5.1 What does the RC20 room controller regulate?
The RC20 room controller regulates the room temperature using
the flow temperature of a heating circuit. The room controller can
be tied into the Energy Management System (EMS) by two
different methods:
– As sole programming unit for the system (factory setting):
The RC20 room controller is fitted in a room (reference room)
and is operated without another programming unit (for example
RC30/RC35) being installed in the heating system.
Example: detached house with one heating circuit.
– As remote control for one heating circuit:
1)
The RC20 room controller is operated in conjunction with a
higher-level programming unit (for example RC30/RC35).
The RC30/RC35 is installed either in a room or on the boiler,
and regulates one heating circuit (e.g. the one in the living
accommodation). The RC20 records the room temperature in
the rented flat and regulates this second heating circuit. Basic
heating system settings are regulated by the RC30/RC35,
which are also made available to the RC20 heating circuit.
Examples: semi-detached or detached house with two heating
circuits (e.g. radiators and underfloor heating system).
1)
Not possible for operation using boilers with UBA 1.x.
