Buhler 435 - Page 133

3-104
435/485/535
Weight Added to Axle (lbs)
Calculated
Weight (kg)
Calculated
Weight (lbs)
C of G Front Rear
Front Weight Bracket 180.115 397.086 -4403 626.479 -229.393
Front Weights (12 X 30 kg) 360 793.664 -4786 1330.100 -536.436
Front Weights (24 X 30 kg) 720 1587.328 -4786 2660.199 -1072.871
Front Weights (40 X 30 kg) 1200 2645.547 -4786 4433.666 -1788.119
Rear Weight Bracket 100.624 221.838 2235 -27.588 249.425
Rear Weights (12 X 30 kg) 360 793.664 2460 -144.488 938.152
Rear Weights (24 X 30 kg) 720 1587.328 2460 -288.975 1876.303
Rear Weights (40 X 30 kg) 1200 2645.547 2460 -481.625 3127.172
Rear Weights (42 X 30 kg) 1260 2777.824 2460 -505.707 3283.531
Upper Weight Bracket 163.288 359.988 897 78.736 281.252
Upper Weights (12 X 30 kg) 360 793.664 1073 137.772 655.892
Upper Weights (24 X 30 kg) 720 1587.328 1073 275.544 1311.784
Upper Weights (40 X 30 kg) 1200 2645.547 1073 459.240 2186.307
Ballasting C of G Calculation Table
Section 3 - Operation
Ballasting
