4-56
435/485/535
Operation 76
Rear Deck Panel Covers Removal
The rear deck panel covers (1) can be removed to gain
access to the right side console controls and VMM unit.
Remove the two 10 mm nuts (2) remove the covers.
The covers are joined together with Velcro for easy
removal and re-installation. (Seat not shown for
clarity).
Operation 77
Fuse and Relay Cover Removal
The fuse and relay panel is located above the right
console. The cover (3) is removed for service by
releasing the two latches (4) and sliding the cover
away. To replace the cover, slide the cover back into
position and re-latch.
1
2 2
4
3
4
Section 4 - Lubrication & Maintenance
As Required
To Next Page
