17
2.4. Dashboard
WHENEVER THE DASHBOARD
IS ILLUMINATED YOUR BRINCO
WILL BE ON BUT IT ONLY WILL BE
IN RUNNING CONDITION WHEN
THE STOP BUTTON IS ON.
5
6
9
10
7
8
1 23
4
Speedometer (km/h - mph) [See 2.5]
Driving mode: ECO - SPORT – TOUR [See 4.5 - 2.9]
To the right of the mode the instantaneous power is shown
in W.
Battery Level
When the battery level falls below 2 bars (22% battery),
the low battery indicator will be shown.
Odometer / Trip [See 2.5]
In-use Indicator
Will be alight when the Brinco is powered on.
Low battery Indicator
Will be alight when 2 or less battery bars are displayed.
Warning Indicator [See 5]
This light flashes when you turn on your Brinco and testing
is being performed. Once testing has finished, the light
will remain on until the motorbike is put in driving position
(and the power button is ON).
Normally, the light will be o. If this light is on it will mean
that something on your Brinco is not working properly, that
it is in self-protection mode or that a system failure has
been detected.
MODE Function [See 2.4]
SET function [See 2.4]
NFC Antenna to lock/unlock your Brinco.
The antenna is connected to the “Biker Manager”, a system
to start the vehicle by means of a pilot wristband/card.
5
6
7
1
2
3
4
9
10
8
