22
2.8. Technical Specifications
ENGINE POWER SYSTEM
Type
Type
Nominal
Capacity
Control
Unit
Charger
Charging
time
(standard)
Three-phase permanent magnet brushless motor.
(Maximum power 2.0kW).
PMAC Brushless radial flow with passive air cooling
with integrated speed and temperature sensors.
Lithium-ion battery cells with integrated
management system “Power Cell Li-Ion Matrix”
(1.3 kWh).
26.1 Ah
> 60 km/h
Three-phase DC/AC controller
(50V-55A Maximum power)
Three selectable driving modes:
SPORT: 2 kW
TOUR: 1.5 kW
ECO 0.9 kW
Regenerative deceleration
Self-diagnostic system
Portable with high performance specifically for the
Bultaco Brinco Li-Ion Matrix Power Cell.
Power 465W
Input 110 VAC - 240 VAC
Output 58.1 VDC / 8A
0%-100% - 3.5h
0%-95% - 3h
0%-80% - 2h
Max speed
without
assisted
pedalling
