29
Connect the Bultaco original charger to the battery and the power outlet (240
V AC 50Hz / 110 V AC 60Hz). Remember that this can be done with the batteries
on the vehicle or with them removed, as shown below.
1. Unplug the power cord
from the battery by hand
turning the connector
housing a quarter turn
counterclockwise and
pulling it out carefully.
2. Enter the key provided
by Bultaco to unlock the
battery safety lock.
3. Remove the retaining
screw while firmly holding
the battery pack. You can
loosen it by hand or with a 5
Allen key.
4. Hold the battery firmly
and rotate it slightly on its
base to release the chassis
anchorage.
3.2. Battery Charge
ALWAYS CHARGE THE BATTERY
WITH THE ORIGINAL BULTACO
BATTERY CHARGER
3.2.1 Removing the battery
1
2
3
4
