4.4.1- Wheel Change
Turn your Brinco upside down and place the seat and handlebars on a flat
surface. Place a wooden block or similar under the handlebar grips to prevent
the display from touching the ground. You should also place a cloth on the
seat so that it does not get stainned or damaged.
Loosen the nuts from the wheel shaft slightly (1) with a 10 Allen key until both
have been disengaged a few millimeters from the shaft. Remove one of the
nuts completely.
Loosen the 4 bolts from the bottom of the fork (2) with a 5 Allen key (they do
not need to be removed completely).
Hold the wheel by pulling it slightly upwards so that the axle stops supporting
all of its weight. Hold the axle by the nut that was not removed (3) and pull to
remove it completely from its housing.
REMOVING THE FRONT WHEEL
BE CAREFUL BECAUSE AS YOU REMOVE
THE AXLE, THE WHEEL WILL START TO
COME LOOSE.
WHEN YOU MOUNT THE WHEEL BACK
YOU SHOULD BE CAREFUL WHEN
INSERTING THE DISC BETWEEN THE
PADS OF THE BRAKE CALIPER.
TO MOUNT THE WHEEL PERFORM THE
PROCESS IN REVERSE ORDER.
i
BEFORE ANY OPERATION, ENSURE YOUR BRINCO IS TURNED OFF
A
B
C
D
