58
4.7. Torques
TORQUES
Assembled part Assembly Thread and Quality Torque (Nm) Safety
Maximum
Torque (Nm)
Power arm with steering post ALLEN BOLT M6x1 DIN 912 8.8 8-10 YES 10
Handlebar with power arm ALLEN BOLT M6x1 DIN 912 8.8 8-10 YES 10
Upper locking plate with bar ALLEN BOLT M6x1 DIN 912 8.8 8-10 YES 10
Fork tip lock ALLEN BOLT M6x1 DIN 912 8.8 8-10 YES 10
Steering Stem Bolt ALLEN BOLT M6x1 DIN 912 8.8 11-13 YES 13.5
Hand Grip with chassis ALLEN BOLT M8x1.25 TITANIUM 22-24 28
Subframe saddle with chassis ALLEN BOLT M8x1.25 TITANIUM 22-24 YES 28
Upper Battery Bracket with chassis ALLEN BOLT M5x0.8 DIN 912 8.8 4.5 -5.5 Sealed YES 5.5
Swivel screw with rocker shaft HEXAGONAL BOLT M8x1.25 8.8 22-24 Sealed YES 24
Rear shock absorber with chassis ALLEN BOLT M8x1.25 TITANIUM 22-24 YES 28
Rear shock absorber with rocker ALLEN BOLT M8x1.25 TITANIUM 22-24 YES 28
Front wheel axle with fork M16x1.5 Al-6061 15-20 YES 30
Front Brake Disc with spool TORX BOLT M5x0.8 8.8 4.5 -5.5 Sealed YES 5.5
Motor Shaft with rocker NUT M14x1.5 80-85 YES 120
Rear brake disc with engine TORX BOLT M5x0.8 8.8 4.5 -5.5 Sealed YES 5.5
Front brake caliper with wheel fork BOLT M6x1 8.8 8-10 Sealed YES 10
Rear brake caliper with rocker BOLT M6x1 8.8 8-10 Sealed YES 10
Pedal rods to axis pedals BOLT M10x1 10.9 50-55 YES 65
With rod Pedal THREAD 9/16 x 20 PPI 48-54 YES 55
Left housing Schlumpf box with chassis THREAD D31x1 140-160 YES 160
Derailleur with chain support cradle M10x1 Al-6061 17-20 Sealed YES 20
With Controller chassis ALLEN BOLT M5x0.8 8.8 4.5-5.5 Sealed YES 5.5
Flange saddle with chassis saddle ALLEN BOLT M6x1 DIN 912 8.8 8-10 10
Biker manager with chassis SELF TAPPING SCREW D4.8 3.5-4 4
