16 - 0911
english
3 TECHNICAL DATA
• Housing ABS, self-extinguishing
• Dimensions Front 74 x 32 mm, Depth 60 mm
• Assembly Panel-mounting unit for 29 x 71 mm cutout
• Protection class IP65 from front, only with front seal RG-C
IP20
• Connections Screw terminals
• Pipe cross-section ≤2.5 mm
2
• Auxiliary energy depending on model
12...24 V AC/DC; ±10%
230 V AC; ±10%; 50/60 Hz
optional 110 V AC; ±10%; 50/60 Hz
• Power consumption max. 3 VA
• Display three digits, red LED, height 12 mm
• Inputs configurable NTC / PTC or
NTC / PTC / Pt100 / Thermoelement J, K, S
or 4...20 mA / 0...1 V / 0...10 V
• Relay outputs 2 x NO 8(3) A, 250 V AC + 1 x NC
• Other outputs acoustic alarm (optional)
• Data memory EEPROM
• Ambient temperature 0 ... +60°C / +32 ... +140°F
• Storage temperature -30 ... +85°C / -22 ... +185°F
• Air humidity 20 ... 85% (non-condensing)
• Measurement range according to sensor
• Resolution 0.1°C or 1°F
• Accuracy at + 25 °C better than 0.5% of the measurement range
