Burkert 8221 - Product with 4 Electrodes, with PG13.5 Connection; Product with 2 Electrodes and a Cable

8.3. Product with 4 electrodes, with
PG13.5 connection
Signal description
VarioPin *
Bürkert
controller
Type 8619
Pin
Cable
colour
Pt1000 E white 9 TS
Pt1000 F green 7 SE
Current electrode
(high end)
B red 1 C+
Potential electrode
(high end)
A transparent 2 P+
Potential electrode
(low end)
C grey 3 P–
Current electrode
(low end)
D blue 4 C–
Not connected on
product
shield green/yellow 6 FE
-
PLEASE NOTE:
→ short 7 SE
and 8 TS
* The cable colours are only valid for the Bürkert VarioPin connection cables
with article number: 554855, 554856, 554857.
8.4. Product with 2 electrodes and a
cable
Signal description Cable
colour
Bürkert controller Type 8619
Pt1000 red 9 TS
Pt1000 green 7 SE
Potential electrode
(low end)
white 3 P–
Potential electrode
(high end)
black 2 P+
Shield transparent 6 FE
-
PLEASE NOTE:
→ short 7 SE and 8 TS
→ short 2 P+ et 1 C+
→ short 3 P– and 4 C–
28
Wiring
Type 8221
English
