Warning
Risk of injury due to nonconforming installation.
▶ The electrical and fluid installation can only be carried out by
qualified and skilled staff with the appropriate tools.
▶ Respect the assembly instructions for the fitting and/or the
holder used.
Risk of injury due to unintentional switch on of power supply
or uncontrolled restarting of the installation.
▶ Avoid unintentional activation of the installation.
▶ Guarantee a set or controlled restarting of the process subse-
quent to any intervention.
7.2. Product with 2 electrodes and a
clamp connection
Install the product in the following ways: onto a pipe (chap. 7.2.1) or
on a vessel (chap. 7.2.2).
7.2.1. Installation onto the pipe
→ Choose an appropriate tee-fitting for the installation of the
product.
→ Make sure the seals are in good condition.
→ Place seals adapted to the process (temperature, fluid type) in the
grooves of the Clamp fitting.
→ Mount the tee-fitting in the pipe. Obey the mounting instructions
given with the fitting.
→ Make sure the electrodes will always be completely immersed in
the liquid.
→ Make sure no air bubbles will disturb the measurements.
→ Choose an appropriate clamp collar.
→ For the article number 564898 carry out the mounting procedure
on Fig. 3.
→ For the article number 564899 or 562261 carry out the mounting
procedure on Fig. 4.
→ For the article number 568818 or 569643 carry out the mounting
procedure on Fig. 3 or on Fig. 4.
17
Installation
Type 8221
